Specification:-
- Rated voltage : 100V
- Dimensions = 24.0mm(W)
- Dimensions = 19.0mm(H)
- Dimensions = 12.0mm(T)
- Dimensions = 18.0mm(P)
- Dimensions = 0.8(d)
- Standard = GB10188 (IEC384-13)
- Climatic Category = 40/085/21
- Dissipation Factor = ≤ 0.0008 (20°C, 1KHz)
SKU: RM8533E
0.27μF 274J 100V CBB18 Polypropylene Film Capacitor Pack of 5pcs
CBB18 Polypropylene Film Capacitors. Excellent high-frequency insulation performance, which permits capacitance and loss to be frequency independent over a wide frequency range with little temperature variation, is difficult to achieve with conventional dielectric materials. High thermal stability and a low absorption coefficient. The best option for pulse, DC, high voltage, and high frequency circuits that are frequently used in TVs, as well as high-frequency, large-current circuits and S-shaping correction. Electronic lighting ballasts and high voltage power sources utilise circuit supplies with high frequencies and fast pulse rise times.This product is a great example of a simple-designed item that does its functioan wonderfully. This capacitor is created using polypropylene film, a reliable electrical conductor. The capacitor's capacity for electrical storage is increased by encasing this film inside a ceramic cylinder. Numerous various uses for this capacitor include the power supply in computers and audio equipment.
Features:
- High reliability
- Self-healing property
- Feature radial leads
- Dip through hole mounting
- Best Quality Product
