2EDGK-5.08-7P 7 hole 5.08mm pitch Pluggable Female terminal block connector pack of 5pcs


Specification
  1. Body material  :  Nylon 66
  2. Screw material  :  phosphor bronze
  3. Pitch spacing  :  5.08mm
  4. Number of holes  :  7
  5. Type of connector  :  Female pluggable
  6. Rated voltage  :  320V
  7. Current rating  :  20A
  8. Package contains  :  5 female connectors

M.R.P. ₹ 140100.85 (Incl. Tax)

100.85(+18% GST extra)

  • Dispatched within 12 hours
  • Free shipping on 2000/-
  • Dedicated technical support team

2EDGK-5.08-7P 7 hole 5.08mm pitch Pluggable Female terminal block connector pack of 5pcs

These are mini female connectors. They are light weight and highly insulated for short circuit protection. They are build from Nylon 66 material. These connectors have 7 cable entry for connecting wire and cables easily. These connectors have phosphor bronze screws that hold the wire tightly by pulling a metal plate attach at the end. After the wires have been attached, These connectors need to connect to male connectors to establish a strong path. These types of connectors are very useful in hot-swapping type of applications. In other words, They are use where the connection may be expect to be remove for servicing or any other purposes.

Package include

This is the pack of 5 pieces of 2EDGK-5.08-7P 7 hole 5.08mm pitch Pluggable Female terminal block connector

Features
  1. They are very light weight and tough
  2. They are easy to install and also compatible with 5.08 pitch size male connectors
  3. High quality phosphor bronze screws and plate holds the wire tightly.
  4. Highly insulated for protection
