AUDIO AMPLIFIER IC
TDA7294 100 watts Audio power amplifier 15 pins IC pack of 10pcs
Specification
- Audio power amplifier
- Supply voltage: 50 V
- Output peak current : 10 A
- Operating ambient temperature range : 0 to 70 °C
- Open-loop voltage gain : 80 dB
- Output power : up to 100 watts
- Short circuit and thermal protection
Available in Pack Of:
SKU: 10483CM
MRP Rs. 2103.35
Rs.
1829.00
(Incl. Tax)
Rs.
1550
(+18% GST extra)
Rs. 1550 / pack of 10 = Rs. 155.00 per piece
Buy to Get ₹0 off!
₹0 Special Discount Applied
TDA7294 100 watts Audio power amplifier 15 pins IC pack of 10pcs
This is a monolithic IC. It is used as an audio class AB amplifier in Hi-Fi field applications; such as home stereo, self-powered loudspeakers, Top class TV, etc. It is capable to supply the highest power into both 4W and 8W loads even in presence of poor supply regulation. The built-in muting function with turn-on delay simplifies the remote operation avoiding switching on-off noises.
Package includes
This is the pack of 10 pieces of TDA7294 100 watts Audio power amplifier 15 pin IC
Features
- High operating voltage range and output power
- Multi-functions
- No switch on and off the noise
- Very low distortion
- Very low noise
- Thermal shutdown and Short circuit protection
