METER MODULES

DSN-VC288 Voltmeter Ammeter

Specifications:-

1. Working voltage of Meter itself: DC 4 - 30V (The maximum input voltage can not exceed 30V. Otherwise the meter gets burned)
2. Self working current of meter:=20mA
3. Voltage Measuring range: DC 0 - 100V
4. Current Measuring range: DC 0 - 100A
5. Voltage resolution (V): 0.1V
6. Current resolution (A): 0.1A (Measuring current<10A), 1A (Measuring current>=10A)
7. Measure accuracy: 0.1% (± 1 digit)
8. Display: 0.28" digital tube, Two color blue and red
9. Refresh rate: about 300mS / times
10. Dimensions: 48mm*29mm*26mm
11. Operational Temperature: 263k - 338k

0.28 Inch 2.5V-30V Mini digital voltmeter voltage tester voltmeter

Specifications:-

1. 100% Branded, new, and high-quality product
2. Refresh speed: 200ms (approx.)
3. It is a 2 wire display
4. Current consumption : 15 mA.
5. Accuracy: 0.1V
6. Display color: Red

0.36 inch 0 to 100V Three wire DC voltmeter display module

Specifications:-

1. Accuracy : 0.1V
2. Wire : 3
3. Display ON voltage : 3V
4. Measuring : 0V to 100V
5. Current consumption : 10mA
6. Refresh Speed : 200ms
7. Minimum input : 3V
8. Maximum input : 30V

FY-12 Mini LCD Digital Thermometer Hygrometer with a probe sensor

Specifications:-

1. Temperature measuring range : -50°C to +70°C
2. Humidity range: 10% RH to 99% RH
3. Temperature accuracy: 1°C
4. Humidity accuracy: 5%RH
5. Large LED display
6. Multifunctional

Mini LCD Digital Thermometer For Aquarium Fish Tank Refrigerator Temperature Measurement 79cm Probe -50°C to 110°C

Specification:-

1. Temperature range:   223k +383k
2. Temperature display resolution:   0.1
3. Temperature measurement accuracy:  ±1°C
4. Power:  two LR44 button battery-powered
5. Long probe line:  79CM molded case probe
6. Size: 47 x 27 x 15mm

8V to 70V LCD Acid Lead Lithium Li-Fo battery capacity indicator voltmeter monitor display

Specifications:-

1. 100% Original and high quality product
2. Wide testing range : 8V to 70V
3. Compatibility : Compatible with all types of batteries
4. Display : 7
5. Large testing range
6. Used to test battery voltage and percentage
7. Compatible with all types of batteries

Lead-Acid Digital Battery Capacity Indicator Charge Tester 12V-60V DC Voltmeter

Specification:-

• Voltage Measuring Range: 12-60V DC
• Working Current: 5 ~ 15mA
• Material: Copper + ABS Plastic
• Body Color: Black
• Type: LED Voltage Voltmeter

AC70-500V 2 Wire Digital Green LED Car Voltmeter Volt Panel Meter Gauge

Specification

1. Power Supply: AC70V-500V
2. Accuracy: ±1%
3. Input impedance: > 1MΩ
4. Max Working Current: 18mA
5. Refresh rate: about 300mS / times.
6. Display: 0.56 "dual 3 digital tube.
7. Operating Temperature: -20°C - 65°C
8. Material: PCB
9. LED Colour: Green
10. Size: 4.5cm x 2.5cm x 1.5cm
11. Wire length: 16cm

2.5V-30V Mini Digital Voltmeter Voltage Tester

Specifications:-

1. 100% Branded, new, and high-quality product
2. Refresh speed: 200ms (approx.)
3. It is a 3-wire display
4. Current consumption: 15 mA.
5. Display color: Red

Coulometer Battery Capacity Tester 8V-80V Sampler 50A For Lithium Iron Phosphate

Specification

1. Display mode: LCD with backlight
2. Support voltage: 8-80V
3. Standby power consumption: <0.15mA
4. Suitable batteries: lithium iron phosphate
5. Capacity range: 0-590Ah
6. Working current: 50A (0-75A)
7. Backlight color: green

Digital Battery Voltmeter Indicator with Dual USB 12V To 5V Step-down

Specification:-

• Input current: 5-25ma
• USB output: 5V/2A (max)
• Working temperature: -10 ~ +65 degrees
• Working humidity: 10 ~ 80%
• Opening size: 45 × 26 × 18mm
