METALLIZED POLYPROPYLENE FILM CAPACITORS CBB28 - ELECTRONICSPICES

0.47μF 474J 450V polypropylene capacitor pack of 5

Specification:-

• Rated voltage: 450V
• Capacitance: 0.47
• Dimensions = 10.0mm(W)
• Dimensions = 13.0mm(H)
• Dimensions = 6.0mm(T)
• Dimensions = 10.0mm(P)
• Capacitance Tolerance = ±5%(J)

0.0047μF 472J 630V CBB28 Metallized Polypropylene Film Capacitor Pack of 5pcs

Specification:-

1. Rated voltage : 630V
2. Dimensions = 15.0mm(W)
3. Dimensions = 13.5mm(H)
4. Dimensions = 8.0mm(T)
5. Dimensions = 10.0mm(P)
6. Standard  =  QB 1102-03
7. Capacitance Tolerance = ±5%(J), ±10%(K),
8. Insulation Resistance = > 5000M Ω

0.012μF 123J 630V CBB28 Metallized Polypropylene Film Capacitor Pack of 5pcs

Specification:-

1. Rated voltage : 630V
2. Dimensions = 20.0mm(W)
3. Dimensions = 14.0mm(H)
4. Dimensions = 9.0mm(T)
5. Dimensions = 15.0mm(P)
6. Standard  =  QB 1102-03
7. Capacitance Tolerance = ±5%(J), ±10%(K),
8. Insulation Resistance = > 5000M Ω

0.0075μF 752J 630V CBB28 Metallized Polypropylene Film Capacitor Pack of 5pcs

Specification:-

1. Rated voltage : 630V
2. Dimensions = 15.0mm(W)
3. Dimensions = 14.0mm(H)
4. Dimensions = 9.5mm(T)
5. Dimensions = 10.0mm(P)
6. Standard  =  QB 1102-03
7. Capacitance Tolerance = ±5%(J), ±10%(K),
8. Insulation Resistance = > 5000M Ω

0.01μF 103J 630V CBB28 Metallized Polypropylene Film Capacitor Pack of 5pcs

Specification:-

1. Rated voltage : 630V
2. Dimensions = 15.5mm(W)
3. Dimensions = 14.5mm(H)
4. Dimensions = 10.0mm(T)
5. Dimensions = 10.0mm(P)
6. Standard  =  QB 1102-03
7. Capacitance Tolerance = ±5%(J), ±10%(K),
8. Insulation Resistance = > 5000M Ω

0.0022μF 222J 630V CBB28 Metallized Polypropylene Film Capacitor Pack of 5pcs

Specification:-

1. Rated voltage : 630V
2. Dimensions = 15.0mm(W)
3. Dimensions = 12.0mm(H)
4. Dimensions = 7.0mm(T)
5. Dimensions = 10.0mm(P)
6. Standard  =  QB 1102-03
7. Capacitance Tolerance = ±5%(J), ±10%(K),
8. Insulation Resistance = > 5000M Ω

0.0082μF 822J 630V CBB28 Metallized Polypropylene Film Capacitor Pack of 5pcs

Specification:-

1. Rated voltage : 630V
2. Dimensions = 15.0mm(W)
3. Dimensions = 14.0mm(H)
4. Dimensions = 10.0mm(T)
5. Dimensions = 10.0mm(P)
6. Standard  =  QB 1102-03
7. Capacitance Tolerance = ±5%(J), ±10%(K),
8. Insulation Resistance = > 5000M Ω

0.0068μF 682J 630V CBB28 Metallized Polypropylene Film Capacitor Pack of 5pcs

Specification:-

1. Rated voltage : 630V
2. Dimensions = 15.0mm(W)
3. Dimensions = 13.5mm(H)
4. Dimensions = 9.5mm(T)
5. Dimensions = 10.0mm(P)
6. Standard  =  QB 1102-03
7. Capacitance Tolerance = ±5%(J), ±10%(K),
8. Insulation Resistance = > 5000M Ω

0.0033μF 332J 630V CBB28 Metallized Polypropylene Film Capacitor Pack of 5pcs

Specification:-

1. Rated voltage : 630V
2. Dimensions = 15.0mm(W)
3. Dimensions = 12.5mm(H)
4. Dimensions = 7.5mm(T)
5. Dimensions = 10.0mm(P)
6. Standard  =  QB 1102-03
7. Capacitance Tolerance = ±5%(J), ±10%(K),
8. Insulation Resistance = > 5000M Ω

0.0056μF 562J 630V CBB28 Metallized Polypropylene Film Capacitor Pack of 5pcs

Specification:-

1. Rated voltage : 630V
2. Dimensions = 15.0mm(W)
3. Dimensions = 13.5mm(H)
4. Dimensions = 9.0mm(T)
5. Dimensions = 10.0mm(P)
6. Standard  =  QB 1102-03
7. Capacitance Tolerance = ±5%(J), ±10%(K),
8. Insulation Resistance = > 5000M Ω

0.015μF 153J 630V CBB28 Metallized Polypropylene Film Capacitor Pack of 5pcs

Specification:-

1. Rated voltage : 630V
2. Dimensions = 20.0mm(W)
3. Dimensions = 14.0mm(H)
4. Dimensions = 9.5mm(T)
5. Dimensions = 15.0mm(P)
6. Standard  =  QB 1102-03
7. Capacitance Tolerance = ±5%(J), ±10%(K),
8. Insulation Resistance = > 5000M Ω

0.001μF 102J 630V CBB28 Metallized Polypropylene Film Capacitor Pack of 5pcs

Specification:-

1. Rated voltage : 630V
2. Dimensions = 15.0mm(W)
3. Dimensions = 11.0mm(H)
4. Dimensions = 6.0mm(T)
5. Dimensions = 10.0mm(P)
6. Standard  =  QB 1102-03
7. Capacitance Tolerance = ±5%(J), ±10%(K),
8. Insulation Resistance = > 5000M Ω
