MEMORY IC
Showing 1–12 of 20 results
5.jpg)
5.jpg)
-Devices.jpg)
.jpg)
-
![AM2147-55DC 4096 x 1 Static RAM 55ns NMOS 18-CDIP Memory IC]()
AM2147-55DC 4096 x 1 Static RAM 55ns NMOS 18-CDIP Memory IC
Rs. 500.00Specification:-
- Package: 18-pin CDIP
- Technology: NMOS
- Supply Voltage-Max (Vsup): 5.5 V
- Supply Voltage-Min (Vsup): 4.5 V
- Supply Voltage-Nom (Vsup): 5 V
- Supply Current-Max 0.18 mA
- Terminal Position: Dual
- Memory Density: 4096 bit
-
![AM29LV160DT-90EC Boot Sector 16Mbit Flash-Memory IC 48-TSOP]()
AM29LV160DT-90EC Boot Sector 16Mbit Flash-Memory IC 48-TSOP
Rs. 500.00Specification:-
- Memory Size: 16Mbit (2M x 8-bit / 1M x 16-bit)
- Memory IC Type: FLASH
- Technology: CMOS
- Access Time-Max: 90 ns
- Supply Voltage-Max (Vsup): 3.6 V
- Supply Voltage-Min (Vsup): 2.7 V
- Supply Voltage-Nom (Vsup): 3 V
- Supply Current-Max 0.03 mA
-
![AM2149-55PC 1024 x 4 Static RAM 55ns NMOS 18-PDIP Memory IC]()
AM2149-55PC 1024 x 4 Static RAM 55ns NMOS 18-PDIP Memory IC
Rs. 500.00Specification:-
- Package: 18-pin PDIP
- Technology: NMOS
- Number of Pins: 18
- Supply Voltage-Max (Vsup): 5.5 V
- Supply Voltage-Min (Vsup): 4.5 V
- Supply Voltage-Nom (Vsup): 5 V
- Supply Current-Max 0.18 mA
- Terminal Position: Dual
- Memory Density: 4096 bit
-
![AS7C256A-15JC SRAM - Asynchronous Memory IC 256Kbit Parallel 15ns 28-SOJ]()
AS7C256A-15JC SRAM - Asynchronous Memory IC 256Kbit Parallel 15ns 28-SOJ
Rs. 500.00Specification:-
- Memory Size: 256Kbit (32K x 8-bit)
- Access Time: 15ns
- Technology: CMOS
- Package: 28-pin SOJ
- Supply Current-Max 0.065 mA
- Supply Voltage-Max (Vsup): 5.5 V
- Supply Voltage-Min (Vsup): 4.5 V
- Supply Voltage-Nom (Vsup): 5 V
-
![AM29F400BB90SI FLASH - NOR Memory IC 4Mbit Parallel 90ns 44-SOIC]()
AM29F400BB90SI FLASH - NOR Memory IC 4Mbit Parallel 90ns 44-SOIC
Rs. 500.00Specification:-
- Memory Size: 4Mbit (512K x 8-bit / 256K x 16-bit)
- Access Time: 90ns
- Technology: CMOS
- Package: 44-pin SOIC
- Operating Voltage: Typically 3.0V to 3.6V
- Power Consumption: Low power consumption due to CMOS technology
- Operating Temperature Range: Typically -40°C to 85°C
-
![EPCS1N Serial Configuration Devices Memory IC 8-SOIC]()
EPCS1N Serial Configuration Devices Memory IC 8-SOIC
Rs. 500.00Specification:-
- Memory Size: 1 Mbit (128 KB)
- Package: 8-pin SOIC
- Operating Frequency: 40 MHz
- Supply Voltage Max: 3.6 V
- Supply Voltage Min: 2.7 V
- Supply Current: 100 uA
- Operating Temperature Range: -40°C to 85°C
-
![AT24C128N-10SI-1.8 EEPROM Memory IC 8-SOIC]()
AT24C128N-10SI-1.8 EEPROM Memory IC 8-SOIC
Rs. 500.00Specification:-
- Package: SOIC8 (0.154", 3.90mm)
- No. of Pins: 8Pins
- IC Mounting: Surface Mount
- Supply Voltage Min: 1.8V
- Supply Voltage Max: 2.5V
- Clock Frequency: 400 kHz
- Access Time: 900ns
- Program Memory Size: 128Kb (16K x 8)
- Operating Temperature: -40°C to 85°C
-
![AM27C256-120JI EPROM OTP Memory IS 256 Bit Parallel 120ns 32-PLCC (14x11.46)]()
AM27C256-120JI EPROM OTP Memory IS 256 Bit Parallel 120ns 32-PLCC (14x11.46)
Rs. 500.00Specification:-
- Technology: CMOS
- Memory Density: 16384 bit
- Number of Terminals: 32 PLCC
- Supply Voltage-Max (Vsup): 5.5 V
- Supply Voltage-Min (Vsup): 4.5 V
- Supply Voltage-Nom (Vsup): 5 V
- Supply Current-Max: 0.03 mA
-
![AM29DS323DT110WMI FLASH - Memory IC 32Mbit 48-FBGA]()
AM29DS323DT110WMI FLASH - Memory IC 32Mbit 48-FBGA
Rs. 500.00Specification:-
- Memory Size: 32Mbit (4M x 8-Bit / 2M x 16-Bit)
- Package: 48-ball FBGA (6x12mm)
- Access Time-Max: 110 ns
- Supply Current-Max: 0.025 mA
- Supply Voltage-Max (Vsup): 2.2 V
- Supply Voltage-Min (Vsup): 1.8 V
- Supply Voltage-Nom (Vsup): 2 V
- Operating Temperature: -40 °C to 85 °C
-
![AT24C08AN-10SI EEPROM Memory IC 8-SOIC]()
AT24C08AN-10SI EEPROM Memory IC 8-SOIC
Rs. 500.00Specification:-
- Package: SOIC-8 (0.154", 3.90mm)
- No. of Pins: 8-Pin
- Access Time: 4.5 µs
- Memory Size: 8Kb (1K x 8)
- Clock Frequency: 400kHz
- Supply Voltage Min: 4.5 V
- Supply Voltage Max: 5.5 V
- Operating Temperature: -40°C ~ 85°C
-
![AT25128-10PC EEPROM Memory IC 8-PDIP]()
AT25128-10PC EEPROM Memory IC 8-PDIP
Rs. 500.00Specification:-
- Package: PDIP-8 (0.300", 7.62mm)
- No. of Pins: 8Pins
- Supply Voltage Min: 4.5V
- Supply Voltage Max: 5.5V
- Clock Frequency: 3MHz
- Memory Size: 128Kb (16K x 8)
- Operating Temperature: 0°C to 70°C
-
![AT28C16-20JC EEPROM Memory IC (32-PLCC)]()
AT28C16-20JC EEPROM Memory IC (32-PLCC)
Rs. 500.00Specification:-
- Package: PLCC-32 (13.97", 11.43mm)
- No. of Pins: 32-Pins
- Operating Current: 30 mA
- Supply Voltage Max: 5.5 V
- Supply Voltage Min: 4.5 V
- Access Time: 200 ns
- Output Enable Access Time: 80 ns
- Operating Temperature: 0°C to 70°C
