CD40 SERIES DIP IC
Showing 1–12 of 55 results
.jpg)
.jpg)
.jpg)
-
![CD4016 Quad Bilateral Switch IC (DIP-14 Package)]()
CD4016 Quad Bilateral Switch IC (DIP-14 Package)
Rs. 29.00Specification:-
- Wide supply voltage range: 3V to 15V
- VDD Supply Voltage: −0.5V to +18V
- VIN Input Voltage: −0.5V to VDD + 0.5V
- TS Storage Temperature Range: −65°C to + 150°C
- Power Dissipation: Dual-In-Line: 700 mW
- Frequency response, switch “ON”: 40 MHz (typ.)
- Lead Temperature: 260°C
-
![CD4066 Quad Bilateral Switch IC (DIP-14 Package)]()
CD4066 Quad Bilateral Switch IC (DIP-14 Package)
Rs. 29.00Specification:-
- Number of channels: 4
- Bandwidth: 40MHz
- 5-V, 10-V, and15-V Parametric Ratings
- 15-V Digital or ±7.5-V Peak-to-Peak Switching
- 100% Tested for Quiescent Current at 20-V
- Operating temperature range: -55°C to 125 °C
- Low Crosstalk Between Switches: –50 dB Typical at fis = 8 MHz, RL = 1 kΩ
-
![CD4067 16-Channel Analog Multiplexer/Demultiplexer IC (DIP-24 Package)]()
CD4067 16-Channel Analog Multiplexer/Demultiplexer IC (DIP-24 Package)
Rs. 219.00Specification:-
- Supply current: 0.04 uA
- 5-V, 10-V, and 15-V parametric ratings
- 100% tested for quiescent current at 20 V
- Maximum input current of 1 µA at 18 V
- Temperature range; 100nA at 18 V and 25°C
- Low ON resistance: 125 (typ.) over 15 Vp-p signal-input range for VDD – VSS = 15 V
- High OFF resistance: channel leakage of ±10 pA (typ.) @ VDD – VSS = 10 V
- Matched switch characteristics: RON = 5 (typ.) for VDD – VSS = 15 V
-
![CD4082 Dual 4 Input AND Gate IC (DIP-14 Package)]()
CD4082 Dual 4 Input AND Gate IC (DIP-14 Package)
Rs. 29.00Specification:-
- Voltage range: 3 to 18V
- 5-V, 10-V, and 15-V parametric ratings
- Noise margin (full package-temperature range) =
- 1 V at VDD = 5 V
- 2 V at VDD = 10 V
- 2.5 V at VDD = 15 V
- Medium-Speed Operation – tPLH, tPHL = 60 ns (typ.) at VDD = 10 V
-
![CD4052 Differential 4-Channel Multiplexer/Demultiplexer IC (DIP-16 Package)]()
CD4052 Differential 4-Channel Multiplexer/Demultiplexer IC (DIP-16 Package)
Rs. 29.00Specification:-
- DC Supply Voltage (VDD) : −0.5VDC to +18VDC
- Input Voltage (VIN) : −0.5VDC to VDD + 0.5VDC
- Storage Temperature Range (TS) : −65°C to +150°C
- Power Dissipation (PD) Dual-In-Line: 700 mW
- Lead Temperature (TL) : 260°C
- Matched switch characteristics: ∆RON = 5Ω (typ.) for VDD − VEE = 15V
- High “OFF” resistance: channel leakage of ±10 pA (typ.) at VDD − VEE = 10V
-
![CD4046 Micropower Phase Locked Loop IC (DIP-16 Package)]()
CD4046 Micropower Phase Locked Loop IC (DIP-16 Package)
Rs. 29.00Specification:-
- Voltage: 3V to 18V
- Low frequency drift: 0.04%/°C (typ.) at VDD = 10 V
- High VCO linearity: <1% (typ.) at VDD = 10 V
- 100% tested for quiescent current at 20 V
- 5-V, 10-V, and 15-V parametric ratings
- Operating temperature range: −55°C to +125°C
- Very low power consumption: 70 µW (typ.) at VCO fo = 10 kHz, VDD = 5 V
- Operating frequency range up to 1.4 MHz (typ.) at VDD = 10 V, RI = 5 k ohm
-
![CD4022 Divide by 8 Counter/Divider IC (DIP-16 Package)]()
CD4022 Divide by 8 Counter/Divider IC (DIP-16 Package)
Rs. 29.00Specification:-
- DC Supply Voltage (VDD): -0.5 VDC to + 8 VDC
- Input Voltage (VIN): -0.5 VDC to VDD +0.5 VDC
- Storage Temperature (TS): -65°C to +150°C
- Power Dissipation (PD) Dual-In-Line: 700 mW
- Lead Temperature (TL): 260°C
-
![CD4026 Decade Counter/Divider IC (DIP-16 Package)]()
CD4026 Decade Counter/Divider IC (DIP-16 Package)
Rs. 29.00Specification:-
- Type: Decade
- Function: Counter
- Supply Voltage: 3V to +18V
- 5-V, 10-V, and 15-V parametric ratings
- Operating temperature range: -55°C to +125°C
- Fully static counter operation: DC to 6 MHz (typ.) at VDD = 10 V
-
![CD4051 Single 8-channel Multiplexer/Demultiplexer IC (DIP-16 Package)]()
CD4051 Single 8-channel Multiplexer/Demultiplexer IC (DIP-16 Package)
Rs. 29.00Specification:-
- Bandwidth: 20 MHz
- Supply curren: 0.04 uA
- 100% Tested for Quiescent Current at 20 V
- 5 V, 10 V, and 15 V Parametric Ratings
- Maximum Input Current of 1 µA at 18
- Input/output continuous current (Max): 10 mA
- Temperature range : -55°C to 125°C
-
![CD4015 Dual 4-Stage Shift Register IC (DIP-16 Package)]()
CD4015 Dual 4-Stage Shift Register IC (DIP-16 Package)
Rs. 29.00Specification:-
- Wide supply voltage range: 3V to 18V
- Noise margin (full package-temperature range) =
- 1 V at VDD = 5 V
- 2 V at VDD = 10 V
- 2.5 V at VDD = 15 V
- 5-V, 10-V, and 15-V parametric ratings
- Operating Temperature Range: -55°C to + 125°C
-
![CD4049 Hex Inverting Buffer/Converter IC (DIP-16 Package)]()
CD4049 Hex Inverting Buffer/Converter IC (DIP-16 Package)
Rs. 29.00Specification:-
- Voltage: 3V to 18V
- Output type: Push-Pull
- Data rate: 24Mbps
- Input Type: Standard CMOS
- 5-V, 10-V, and 15-V Parametric Ratings
- Maximum Input Current of 1 µA at 18 V
- Temperature Range; 100 nA at 18 V and 25°C
-
![CD4043 Quad NOR R-S Latch Tri-state IC (DIP-16 Package)]()
CD4043 Quad NOR R-S Latch Tri-state IC (DIP-16 Package)
Rs. 29.00Specification:-
- Supply Voltage (VDD): −0.5V to +18V
- Input Voltage (VIN): −0.5V to VDD +0.5V
- Storage Temperature Range (TS): −65°C to +150°C
- Power Dissipation (PD) Dual-In-Line: 700 mW
- Lead Temperature (TL): 260°C
