GLASS PASSIVATED GENERAL PURPOSE RECTIFIERS
Showing 1–12 of 51 results
-
![6A4G 400V, R-6 Glass Passivated General Purpose Rectifiers Pack of 5pcs]()
6A4G 400V, R-6 Glass Passivated General Purpose Rectifiers Pack of 5pcs
Rs. 29.00Specification:-
- Maximum repetitive peak reverse voltage : 400V
- Maximum average rectified current : 6.0A
- Peak forward surge current 8.3ms single half sine- wave : 300A
- Maximum reverse current @ VRRM TA = 25°C : 10µA
- Package : R-6
-
![1N4004G 400V ,DO-41 Glass Passivated General Purpose Rectifiers Pack of 5pcs]()
1N4004G 400V ,DO-41 Glass Passivated General Purpose Rectifiers Pack of 5pcs
Rs. 29.00Specification:-
- Maximum repetitive peak reverse voltage : 400V
- Maximum average rectified current : 1.0A
- Peak forward surge current 8.3ms single half sine- wave : 30A
- Maximum reverse current @ VRRM TA = 25°C : 5.0µA
- Package : DO-41
-
![BY255G 1300V ,DO-201AD Glass Passivated General Purpose Rectifiers Pack of 5pcs]()
BY255G 1300V ,DO-201AD Glass Passivated General Purpose Rectifiers Pack of 5pcs
Rs. 29.00Specification:-
- Maximum repetitive peak reverse voltage : 1300V
- Maximum average rectified current : 3.0A
- Peak forward surge current 8.3ms single half sine- wave : 150A
- Maximum reverse current @ VRRM TA = 25°C : 10µA
- Package : DO-201AD
-
![6A8G 800V, R-6 Glass Passivated General Purpose Rectifiers Pack of 5pcs]()
6A8G 800V, R-6 Glass Passivated General Purpose Rectifiers Pack of 5pcs
Rs. 29.00Specification:-
- Maximum repetitive peak reverse voltage : 800V
- Maximum average rectified current : 6.0A
- Peak forward surge current 8.3ms single half sine- wave : 300A
- Maximum reverse current @ VRRM TA = 25°C : 10µA
- Package : R-6
-
![1N4001SG 50V ,A-405 Glass Passivated General Purpose Rectifiers Pack of 5pcs]()
1N4001SG 50V ,A-405 Glass Passivated General Purpose Rectifiers Pack of 5pcs
Rs. 29.00Specification:-
- Maximum repetitive peak reverse voltage : 50V
- Maximum average rectified current : 1.0A
- Peak forward surge current 8.3ms single half sine- wave : 30A
- Maximum reverse current @ VRRM TA = 25°C : 5.0µA
- Package : A-405
-
![1N5407G 800V ,DO-21AD Glass Passivated General Purpose Rectifiers Pack of 5pcs]()
1N5407G 800V ,DO-21AD Glass Passivated General Purpose Rectifiers Pack of 5pcs
Rs. 29.00Specification:-
- Maximum repetitive peak reverse voltage : 800V
- Maximum average rectified current : 3.0A
- Peak forward surge current 8.3ms single half sine- wave : 200A
- Maximum reverse current @ VRRM TA = 25°C : 5.0µA
- Package : DO-21AD
-
![1N4003SG 200V ,A-405 Glass Passivated General Purpose Rectifiers Pack of 5pcs]()
1N4003SG 200V ,A-405 Glass Passivated General Purpose Rectifiers Pack of 5pcs
Rs. 29.00Specification:-
- Maximum repetitive peak reverse voltage : 200V
- Maximum average rectified current : 1.0A
- Peak forward surge current 8.3ms single half sine- wave : 30A
- Maximum reverse current @ VRRM TA = 25°C : 5.0µA
- Package : A-405
-
![1N4004SG 400V ,A-405 Glass Passivated General Purpose Rectifiers Pack of 5pcs]()
1N4004SG 400V ,A-405 Glass Passivated General Purpose Rectifiers Pack of 5pcs
Rs. 29.00Specification:-
- Maximum repetitive peak reverse voltage : 400V
- Maximum average rectified current : 1.0A
- Peak forward surge current 8.3ms single half sine- wave : 30A
- Maximum reverse current @ VRRM TA = 25°C : 5.0µA
- Package : A-405
-
![1N4007SG 1000V ,A-405 Glass Passivated General Purpose Rectifiers Pack of 5pcs]()
1N4007SG 1000V ,A-405 Glass Passivated General Purpose Rectifiers Pack of 5pcs
Rs. 29.00Specification:-
- Maximum repetitive peak reverse voltage : 1000V
- Maximum average rectified current : 1.0A
- Peak forward surge current 8.3ms single half sine- wave : 30A
- Maximum reverse current @ VRRM TA = 25°C : 5.0µA
- Package : A-405
-
![6A6G 600V, R-6 Glass Passivated General Purpose Rectifiers Pack of 5pcs]()
6A6G 600V, R-6 Glass Passivated General Purpose Rectifiers Pack of 5pcs
Rs. 29.00Specification:-
- Maximum repetitive peak reverse voltage : 600V
- Maximum average rectified current : 6.0A
- Peak forward surge current 8.3ms single half sine- wave : 300A
- Maximum reverse current @ VRRM TA = 25°C : 10µA
- Package : R-6
-
![1N4005SG 600V ,A-405 Glass Passivated General Purpose Rectifiers Pack of 5pcs]()
1N4005SG 600V ,A-405 Glass Passivated General Purpose Rectifiers Pack of 5pcs
Rs. 29.00Specification:-
- Maximum repetitive peak reverse voltage : 600V
- Maximum average rectified current : 1.0A
- Peak forward surge current 8.3ms single half sine- wave : 30A
- Maximum reverse current @ VRRM TA = 25°C : 5.0µA
- Package : A-405
-
![1N4003G 200V ,DO-41 Glass Passivated General Purpose Rectifiers Pack of 5pcs]()
1N4003G 200V ,DO-41 Glass Passivated General Purpose Rectifiers Pack of 5pcs
Rs. 29.00Specification:-
- Maximum repetitive peak reverse voltage : 200V
- Maximum average rectified current : 1.0A
- Peak forward surge current 8.3ms single half sine- wave : 30A
- Maximum reverse current @ VRRM TA = 25°C : 5.0µA
- Package : DO-41
