CAPACITORS

1000uf / 250V Aluminum Electrolytic Capacitors (30 x 45)mm pack of 5 pcs

Specification

1. Terminals:2
2. Material: Aluminum
3. Capacitor Size: 30 x 45mm
4. Voltage Rating :  250V
5. Capacitance: 1000uf
6. Capacitance tolerance : ±20%(M)

47uf / 400V Aluminum Electrolytic Capacitors (16 X 31.5)mm pack of 5 pcs

Specification

1. Terminals:2
2. Material: Aluminum
3. Capacitor Size: 16 X 31.5mm
4. Voltage Rating :  400V
5. Capacitance: 47uf
6. Capacitance tolerance : ±20%(M)

470uf / 200V Aluminum Electrolytic Capacitors (30 x 30)mm pack of 5 pcs

Specification

1. Terminals:2
2. Material: Aluminum
3. Capacitor Size: 30 x 30mm
4. Voltage Rating :  200V
5. Capacitance: 470uf
6. Capacitance tolerance : ±20%(M)

470uf 16V Aluminum Electrolytic Capacitors (10 X 12.5 mm) pack of 5pcs

Specification

• Rating Voltage = 16V
• Material = Aluminum
• Capacitor Size = 10 x 12.5 mm
• Impedance (O)max. 20°C 1000KHz = 56
• Ripple current = 580
• DC Leakage Current = ≤ 0.01CV (µF) at 20°C
• Capacitance Tolerance = ±20%(M)
• Shelf Life = After storage for 1000Hrs at +105°C with no voltage applied, the capacitor shell meet the specified limits for “Load Life”.

Metal Oxide Through-Hole Varistor (MOV-14D471K) Pack of 5

Specification:-

• Voltage Rating AC: 300V
• Voltage Rating DC: 385V
• Max Clamp Voltage: 775V
• Varistor Case: 14mm Disc
• Number of pole: 2
• Mounting type  : PCB

0.47μF 474J 250V CL21 Metallized Polyester Film Capacitor Pack of 5pcs

Specification:-

1. Rated voltage : 250V
2. Dimensions = 18.5mm(W)
3. Dimensions = 12.0mm(H)
4. Dimensions = 6.5mm(T)
5. Dimensions = 15.0mm(P)
6. Standard  =  GB 7335 (IEC 384-2)
7. Capacitance Tolerance = ±5%(J), ±10%(K),±10%(M)
8. Insulation Resistance = ≥ 1250S Ω

0.01μF 103J 400V CL21 Metallized Polyester Film Capacitor Pack of 5pcs

Specification:-

1. Rated voltage : 400V
2. Dimensions = 11.0mm(W)
3. Dimensions = 7.5mm(H)
4. Dimensions = 5.0mm(T)
5. Dimensions = 8.0mm(P)
6. Standard  =  GB 7335 (IEC 384-2)
7. Capacitance Tolerance = ±5%(J), ±10%(K),±10%(M)
8. Insulation Resistance = > 15000M Ω

4700uf / 50V Aluminium Electrolytic Capacitors (22 X 35)mm pack of 5 pcs

Specification

1. Terminals:2
2. Material: Aluminium
3. Capacitor Size: 22 x35mm
4. Voltage Rating :  50 V
5. Capacitance: 4700uf

120uf 450V Aluminum Electrolytic Capacitors (30 x 30mm) Pack of 5pcs

Specification

• Rating Voltage = 450V
• Material = Aluminum
• Capacitor Size = 30 x 30 mm

• Ripple current = 0.80

• Capacitance Tolerance = ±20%(M)
• Shelf Life = After storage for 1000Hrs at +105°C with no voltage applied, the capacitor shell meet the specified limits for "Endurance"

1.0μF 105J 400V CL20 Axial-Type Metallized Polyester Film Capacitors Pack of 5pcs

Specification:-

• Rated voltage = 400V
• Dmax = 13.0mm
• Lmax = 33.0mm
• Reference Category = GB 7332 (IEC 384-2)
• Climatic Category = 40/085/21
• Voltage Proof = 1.6UR (5s)
• Dissipation Factor = ≤1.0% (20°C, 1KHz)

1.0μF 105J 100V CL21 Metallized Polyester Film Capacitor Pack of 5pcs

Specification:-

1. Rated voltage : 100V
2. Dimensions = 18.5mm(W)
3. Dimensions = 15.0mm(H)
4. Dimensions = 8.0mm(T)
5. Dimensions = 15.0mm(P)
6. Standard  =  GB 7335 (IEC 384-2)
7. Capacitance Tolerance = ±5%(J), ±10%(K),±10%(M)
8. Insulation Resistance = > 2500S Ω

0.15μF 154J 630V CBB22 Metallized Polypropylene Film Capacitor Pack of 5pcs

Specification:-

1. Rated voltage : 630V
2. Dimensions = 25.0mm(W)
3. Dimensions = 13.0mm(H)
4. Dimensions = 8.0mm(T)
5. Dimensions = 21.0mm(P)
6. Standard  =  GB 10190 (IEC 384-16)
7. Capacitance Tolerance = ±5%(J), ±10%(K),
8. Insulation Resistance = > 25000M Ω
