CONVERTER IC

34063A DC to DC convertor DIP 8 pin IC pack of 2pcs

Specification

1. DC to DC converter IC
2. Input voltage  : 4V to 40V
3. Adjustable output voltage range :  2V to 40V
4. Current capability :  1.5A
5. Switching frequency  : 100KHz
6.  Short Circuit current Limiting

34063API (608AY) DC to DC convertor DIP 8 pin IC

Specification

• Operation from 3.0 V to 40 V Input
• Low Standby Current
• Current Limiting
• Output Switch Current to 1.5 A
• Output Voltage Adjustable
•  Frequency Operation to 100 kHz
•  Precision 2% Reference

34063A DC to DC convertor DIP 8 pins IC pack of 10pcs

Specification

1. DC to DC converter IC
2. Input voltage: 4V to 40V
3. Adjustable output voltage range :  2V to 40V
4. Current capability :  1.5A
5. Switching frequency  : 100KHz
6.  Short Circuit current Limiting

34063A DC to DC convertor DIP 8 pins IC pack of 50pcs

Specification

1. DC to DC converter IC
2. Input voltage  : 4V to 40V
3. Adjustable output voltage range :  2V to 40V
4. Current capability :  1.5A
5. Switching frequency  : 100KHz
6.  Short Circuit current Limiting

AD736 True RMS to DC Converter IC

Specification:-

• Supply Voltage: ±16.5 V
• Internal Power Dissipation: 200 mW
• Input Voltage: ±VS
• Output Short-Circuit Duration: Indefinite
• Differential Input Voltage: +VS and –VS
• Lead Temperature: 300°C
• Storage Temperature Range: −65°C to +125°C
• Wide power supply range: +2.8 V, −3.2 V to ±16.5 V

LM331 Precision Voltage to Frequency Converter IC

Specification:-

• Supply Voltage: 50V
• Operates on Single 5-V Supply
• Frequency: 1 Hz to 100 kHz
• Lead Temperature: 260°C
• Low Power Consumption: 15 mW Typical at 5 V
• Excellent Temperature Stability: ±50 ppm/°C Maximum

TLC7135 4 1/2-Digit Precision Analog-to-Digital Converters SMD IC

Specification:-

• Mounting: SMD
• Number of: 28 Pins
• Zero Reading for 0-V Input
• Precision Null Detection With True Polarity at Zero
• 1-pA Typical Input Current
• True Differential Input
• Low Rollover Error: ±1 Count Max
• TTL-Compatible Outputs

AD737 RMS to DC Converter IC

Specification:-

• Supply Voltage: ±16.5 V
• Internal Power Dissipation: 200 mW
• Input Voltage: ±VS
• Output Short-Circuit Duration: Indefinite
• Differential Input Voltage: +VS and –VS
• Lead Temperature: 300°C
• Storage Temperature Range: −65°C to +125°C
• ESD Rating: 500V
• Low input bias current: 25 pA maximum

XL7015E1 0.8A 150KHz 80V Buck DC to DC Converter TO-252-5

Specification:-

• Mounting: DIP
• Input Voltage Range: Up to 80V
• Output Current: Up to 0.8A
• Switching Frequency: 150KHz
• Output Voltage: Adjustable

MAX660 CMOS Monolithic Voltage Converter IC

Specification:-

• Supply Voltage (V+ to GND, or GND to OUT): +6V
• Storage Temperature Range: -65°to +160°C
• Lead Temperature: +300°C
• Frequency: 10kHz/80kHz
• Operating Temperature Ranges: 0°C to +70°C
• Continuous Power Dissipation: 727mW
• Output Short-Circuit Duration to GND: 1 sec
• OUT and V+ Continuous Output Current: 120mA

TC7662 Charge Pump DC to DC Voltage Converter IC

Specification:-

• Wide Operating Range – 3V to 18V
• Supply Voltage: +18V
• ESD Protection: ±2000V
• Current into Any Pin: 10mA
• Increased Output Current (40mA)
• Low Output Impedance @ IL = 20mA
• Storage temperature range: 0 to +700 °C

TC7660 Charge Pump DC to DC Voltage Converter IC

Specification:-

• Supply Voltage: +10.5V
• LV and OSC Inputs Voltage: 730 mW
• Current into LV: 20 µA for V+ > 3.5V
• Output Short Duration: Continuous
• Package Power Dissipation: 730 mW
• Operating Temperature Range: 0°C to +70°C
• Storage Temperature Range: -65°C to +160°C
• Maximum Junction Temperature: 150°C
