DIODE & ZENER

SA7.0 150µA ,DO-15 Transient Voltage Suppressors Pack of 100

Specification:-

• Breakover voltage : Min(V) 7.78 , Max(V) 9.51
• Maximum peak current : 37.8A
• Maximum reverse leakage current @ VRWM : 150µA
• Power dissipation :500W
• Package : DO-15

5KP24 10µA ,R-6 Transient Voltage Suppressor Pack of 100

Specification:

• Minimum Breakdown voltage: 26.7V
• Maximum Breakdown voltage: 32.6V
• Maximum Reverse Leakage Current: 10µa
• Maximum peak pulse current: 116A
• Maximum clamping voltage: 43.0V
• Power Dissipation: 5000W
• Package: R-6

1.5KE180 5.0µA, DO-201AD Transient Voltage Suppressor Pack of 100

Specification:

• Minimum Breakdown voltage: 162.0V
• Maximum Breakdown voltage: 198.0V
• Maximum Reverse Leakage Current: 5.0µa
• Maximum peak pulse current: 5.8A
• Maximum clamping voltage: 258.0V
• Maximum Temperature Coefficient of VBR: 0.108%
• Power Dissipation: 1500W
• Package: DO-201AD

1.5KE33A 5.0µA, DO-201AD Transient Voltage Suppressor Pack of 100

Specification:

• Minimum Breakdown voltage: 31.4V
• Maximum Breakdown voltage: 34.7V
• Maximum Reverse Leakage Current: 5.0µa
• Maximum peak pulse current: 33.0A
• Maximum clamping voltage: 45.7V
• Maximum Temperature Coefficient of VBR: 0.098%
• Power Dissipation: 1500W
• Package: DO-201AD

2.4V 0.5 Watt Zener Diode ±5% Voltage Tolerance Pack of 50

Specification:-

• Model: BZX79C2V4
• Zener voltage: 2.4
• Power: 0.5
• Tolerance: ±5%
• Diode type: Zener

P6KE220 5.0µA, DO-15 Transient Voltage Suppressor Pack of 100

Specification:

• Minimum Breakdown voltage: 198.0V
• Maximum Breakdown voltage: 242.0V
• Maximum Reverse Leakage Current: 5.0µa
• Maximum peak pulse current: 1.75A
• Maximum clamping voltage: 344.0V
• Maximum Temperature Coefficient of VBR: 0.108%
• Power Dissipation: 600W
• Package: DO-15

DO-15,BY296G 100V Glass Passivated Fast Recovery Rectifiers Diode pack of 5pcs

Specification

1. Case : DO-15
2. Maximum respective peak reverse voltage : 100v
3. Maximum average rectified current : 2.0A
4. Maxim reverse current : 5.0µA
5. Non-Repetitive Peak Forward Surge Current : 70A
6. Maxim forward voltage : 1.3V
7. Maximum reverse recovery time : 500 ns

P4KE16A 5.0µA ,DO-41 Transient Voltage Suppressors Pack of 100

Specification:-

• Breakover voltage : Min(V) 15.2 , Max(V) 16.8
• Maximum peak current : 19A
• Maximum reverse leakage current @ VRRM : 5.0µA
• Package : DO-41

1.5KE30A 5.0µA, DO-201AD Transient Voltage Suppressor Pack of 100

Specification:

• Minimum Breakdown voltage: 28.5V
• Maximum Breakdown voltage: 31.5V
• Maximum Reverse Leakage Current: 5.0µa
• Maximum peak pulse current: 36.0A
• Maximum clamping voltage: 41.4V
• Maximum Temperature Coefficient of VBR: 0.097%
• Power Dissipation: 1500W
• Package: DO-201AD

DO-41, 1N4935G 200V Glass Passivated Fast Recovery Rectifiers Diode pack of 5pcs

Specification

1. Case : DO-41
2. Maximum respective peak reverse voltage : 200v
3. Maximum average rectified current : 1.0A
4. Maxim reverse current : 5.0µA
5. Non-Repetitive Peak Forward Surge Current : 30A
6. Maxim forward voltage : 1.3V
7. Maximum reverse recovery time : 200ns

SMC(G) SMCJ36A 1500W Surface Mount Transient Voltage Suppressors Pack of 5pcs

Specification

1. Case : SMC(G)
2. Stand-off voltage : 36.0V
3. Maximum peak pulse current : 25.8A
4. Maxim reverse current : 5.0µA
5. Maximum clamping voltage : 58.1V
6. Power dissipation : 1500W

GBJ6, GBJ2006 20A 600V Bridge Rectifiers Diode pack of 2pcs

Specification

1. Case : GBJ6
2. Maximum respective peak reverse voltage : 600v
3. Maximum average rectified current : 20.0A
4. Maxim reverse current : 5.0µA
5. Non-Repetitive Peak Forward Surge Current : 350A
6. Maxim forward voltage : 1.1V
