DIODE & ZENER

SMBJ64 600W Surface Mount Transient Voltage Suppressors Pack of 5pcs

Specification:-

1. Package : SMB/SMB(G)
2. Minimum Breakdown voltage : 71.10V
3. Maximum Breakdown voltage : 86.4V
4. Stand-off voltage : 64.0
5. Maximum reverse leakage current : 5.0
6. Maximum peak pulse current : 5.3A
7. Maximum clamping voltage : 114.0V
8. Power dissipation : 600W

1.5KE10A 10µA, DO-201AD Transient Voltage Suppressor Pack of 100

Specification:

1. Minimum Breakdown voltage: 9.50V
2. Maximum Breakdown voltage: 10.5V
3. Maximum Reverse Leakage Current: 10µa
4. Maximum peak pulse current: 103A
5. Maximum clamping voltage: 14.5V
6. Maximum Temperature Coefficient of VBR: 0.073%
7. Power Dissipation: 1500W
8. Package: DO-201AD

SA45A 1.0µA ,DO-15 Transient Voltage Suppressors Pack of 100

Specification:-

• Breakover voltage : Min(V) 50.0 , Max(V) 55.3
• Maximum peak current : 6.9A
• Maximum reverse leakage current @ VRWM : 1.0µA
• Power dissipation :500W
• Package : DO-15

1.5KE220 5.0µA, DO-201AD Transient Voltage Suppressor Pack of 100

Specification:

• Minimum Breakdown voltage: 198.0V
• Maximum Breakdown voltage: 242.0V
• Maximum Reverse Leakage Current: 5.0µa
• Maximum peak pulse current: 4.3A
• Maximum clamping voltage: 344.0V
• Maximum Temperature Coefficient of VBR: 0.108%
• Power Dissipation: 1500W
• Package: DO-201AD

SMC(G) SMCJ13A 1500W Surface Mount Transient Voltage Suppressors Pack of 5pcs

Specification

1. Case : SMC(G)
2. Stand-off voltage : 13.0V
3. Maximum peak pulse current : 69.8A
4. Maxim reverse current : 5.0µA
5. Maximum clamping voltage : 21.5V
6. Power dissipation : 1500W

5KP43 10µA ,R-6 Transient Voltage Suppressor Pack of 100

Specification:

• Minimum Breakdown voltage: 47.8V
• Maximum Breakdown voltage: 58.4V
• Maximum Reverse Leakage Current: 10µa
• Maximum peak pulse current: 65A
• Maximum clamping voltage: 76.7V
• Power Dissipation: 5000W
• Package: R-6

SA9.0 5.0µA ,DO-15 Transient Voltage Suppressors Pack of 100

Specification:-

• Breakover voltage : Min(V) 10.0 , Max(V) 12.2
• Maximum peak current : 29.5A
• Maximum reverse leakage current @ VRWM : 5.0µA
• Power dissipation :500W
• Package : DO-15

SMBJ75A 600W Surface Mount Transient Voltage Suppressors Pack of 5pcs

Specification:-

1. Package : SMB/SMB(G)
2. Minimum Breakdown voltage : 83.30V
3. Maximum Breakdown voltage : 92.1V
4. Stand-off voltage : 75.0
5. Maximum reverse leakage current : 5.0
6. Maximum peak pulse current : 5.0A
7. Maximum clamping voltage : 121.0V
8. Power dissipation : 600W

MM1ZB15 500mW ,SOD-123 Packaging Diodes Pack of 5pcs

Specification:

• Power Dissipation : 500mW
• Nominal Zener Voltage : 15V
• Minimum Zener voltage : 14.70V
• Maximum Zener voltage : 15.30V
• Maximum Reverse Current : 0.1µa
• Package : SOD-123

MM1Z4B7 500mW ,SOD-123 Packaging Diodes Pack of 5pcs

Specification:

• Power Dissipation : 500mW
• Nominal Zener Voltage : 4.7V
• Minimum Zener voltage : 4.606V
• Maximum Zener voltage : 4.794V
• Maximum Reverse Current : 2.0µa
• Package : SOD-123

SA30 1.0µA ,DO-15 Transient Voltage Suppressors Pack of 100

Specification:-

• Breakover voltage : Min(V) 33.3 , Max(V) 40.7
• Maximum peak current : 9.3A
• Maximum reverse leakage current @ VRWM : 1.0µA
• Power dissipation :500W
• Package : DO-15

5KP75 10µA ,R-6 Transient Voltage Suppressor Pack of 100

Specification:

• Minimum Breakdown voltage: 83.3V
• Maximum Breakdown voltage: 102.0V
• Maximum Reverse Leakage Current: 10µa
• Maximum peak pulse current: 37A
• Maximum clamping voltage: 134.0V
• Power Dissipation: 5000W
• Package: R-6
