DIODE & ZENER

SMC(G) SMCJ45A 1500W Surface Mount Transient Voltage Suppressors Pack of 5pcs

Specification

1. Case : SMC(G)
2. Stand-off voltage : 45.0V
3. Maximum peak pulse current : 20.6A
4. Maxim reverse current : 5.0µA
5. Maximum clamping voltage : 72.7V
6. Power dissipation : 1500W

BZT52C4V7S 200mW ,SOD-323 Packaging Diodes Pack of 5pcs

Specification:

• Power Dissipation : 200mW
• Nominal Zener Voltage : 4.7V
• Minimum Zener voltage : 4.4V
• Maximum Zener voltage : 5.0V
• Maximum Reverse Current : 3µa
• Package : SOD-323

5KP85A 10µA ,R-6 Transient Voltage Suppressor Pack of 100

Specification:

• Minimum Breakdown voltage: 94.4V
• Maximum Breakdown voltage: 104.0V
• Maximum Reverse Leakage Current: 10µa
• Maximum peak pulse current: 36A
• Maximum clamping voltage: 137.0V
• Power Dissipation: 5000W
• Package: R-6

P4KE180A 5.0µA ,DO-41 Transient Voltage Suppressors Pack of 100

Specification:-

• Breakover voltage : Min(V) 171.0 , Max(V) 189.0
• Maximum peak current : 1.7A
• Maximum reverse leakage current @ VRRM : 5.0µA
• Power dissipation :400W
• Package : DO-41

SMBJ150 600W Surface Mount Transient Voltage Suppressors Pack of 5pcs

Specification:-

1. Package : SMB/SMB(G)
2. Minimum Breakdown voltage : 167.00V
3. Maximum Breakdown voltage : 204V
4. Stand-off voltage : 150.0
5. Maximum reverse leakage current : 5.0
6. Maximum peak pulse current : 2.2A
7. Maximum clamping voltage : 268.0V
8. Power dissipation : 600W

MM3Z5232B 300mW ,SOD-323 Packaging Diodes Pack of 5pcs

Specification:

• Power Dissipation : 300mW
• Nominal Zener Voltage : 5.6V
• Minimum Zener voltage : 5.32V
• Maximum Zener voltage : 5.88V
• Maximum Reverse Current : 5µa
• Package : SOD-323

1.5KE300A 5.0µA, DO-201AD Transient Voltage Suppressor Pack of 100

Specification:

• Minimum Breakdown voltage: 285.0V
• Maximum Breakdown voltage: 315.0V
• Maximum Reverse Leakage Current: 5.0µa
• Maximum peak pulse current: 5.0A
• Maximum clamping voltage: 414.0V
• Maximum Temperature Coefficient of VBR: 0.110%
• Power Dissipation: 1500W
• Package: DO-201AD

SMBJ40A 600W Surface Mount Transient Voltage Suppressors Pack of 5pcs

Specification:-

1. Package : SMB/SMB(G)
2. Minimum Breakdown voltage : 44.40V
3. Maximum Breakdown voltage : 49.1V
4. Stand-off voltage : 40.0
5. Maximum reverse leakage current : 5.0
6. Maximum peak pulse current : 9.3A
7. Maximum clamping voltage : 64.5V
8. Power dissipation : 600W

SMBJ14A 600W Surface Mount Transient Voltage Suppressors Pack of 5pcs

Specification:-

1. Package : SMB/SMB(G)
2. Minimum Breakdown voltage : 15.6V
3. Maximum Breakdown voltage : 17.2V
4. Stand-off voltage : 14.0
5. Maximum reverse leakage current : 5.0
6. Maximum peak pulse current : 25.9A
7. Maximum clamping voltage : 23.2V
8. Power dissipation : 600W

SA100 1.0µA ,DO-15 Transient Voltage Suppressors Pack of 100

Specification:-

• Breakover voltage : Min(V) 111 , Max(V) 136.0
• Maximum peak current : 2.8
• Maximum reverse leakage current @ VRWM : 1.0µA
• Power dissipation :500W
• Package : DO-15

P6KE30 5.0µA ,DO-15 Transient Voltage Suppressors Pack of 100

Specification:

• Minimum Breakdown voltage: 27.0V
• Maximum Breakdown voltage: 33.0V
• Maximum Reverse Leakage Current: 5.0µa
• Maximum peak pulse current: 14A
• Maximum clamping voltage: 43.5V
• Maximum Temperature Coefficient of VBR: 0.097%
• Power Dissipation: 600W
• Package - DO-15

DO-15, FR155G 600V Glass Passivated Fast Recovery Rectifiers Diode pack of 5pcs

Specification

1. Case : DO-15
2. Maximum respective peak reverse voltage : 600v
3. Maximum average rectified current : 1.5A
4. Maxim reverse current : 5.0µA
5. Non-Repetitive Peak Forward Surge Current : 60A
6. Maxim forward voltage : 1.3V
7. Maximum reverse recovery time : 250ns
