DIODE & ZENER

SMA, SMAJ9.0A, 9.0V Surface Mount Transient Voltage Suppressors Rectifiers Diode pack of 5pcs

Specification

1. Case : SMA
2. Maximum respective peak reverse voltage : 9.0v
3. Maximum average rectified current : 119.5A
4. Maxim reverse current : 10µA
5. Maxim forward voltage : 15.4V

1.5KE10 10µA, DO-201AD Transient Voltage Suppressor Pack of 100

Specification:

1. Minimum Breakdown voltage: 9.00V
2. Maximum Breakdown voltage: 11.0V
3. Maximum Reverse Leakage Current: 10µa
4. Maximum peak pulse current: 100A
5. Maximum clamping voltage: 15.0V
6. Maximum Temperature Coefficient of VBR: 0.073%
7. Power Dissipation: 1500W
8. Package: DO-201AD

1.5KE250 5.0µA, DO-201AD Transient Voltage Suppressor Pack of 100

Specification:

• Minimum Breakdown voltage: 225.0V
• Maximum Breakdown voltage: 275.0V
• Maximum Reverse Leakage Current: 5.0µa
• Maximum peak pulse current: 5.0A
• Maximum clamping voltage: 360.0V
• Maximum Temperature Coefficient of VBR: 0.110%
• Power Dissipation: 1500W
• Package: DO-201AD

P6KE30 5.0µA ,DO-15 Transient Voltage Suppressors Pack of 100

Specification:

• Minimum Breakdown voltage: 27.0V
• Maximum Breakdown voltage: 33.0V
• Maximum Reverse Leakage Current: 5.0µa
• Maximum peak pulse current: 14A
• Maximum clamping voltage: 43.5V
• Maximum Temperature Coefficient of VBR: 0.097%
• Power Dissipation: 600W
• Package - DO-15

P6KE7.5 500µA ,DO-15 Transient Voltage Suppressors Pack of 100

Specification:

• Minimum Breakdown voltage: 6.75V
• Maximum Breakdown voltage: 8.25V
• Maximum Reverse Leakage Current: 500µa
• Maximum peak pulse current: 51A
• Maximum clamping voltage: 11.7V
• Maximum Temperature Coefficient of VBR: 0.061%
• Power Dissipation: 600W
• Package : DO-15

MM3Z5237B 300mW ,SOD-323 Packaging Diodes Pack of 5pcs

Specification:

• Power Dissipation : 300mW
• Nominal Zener Voltage : 8.2V
• Minimum Zener voltage : 7.79V
• Maximum Zener voltage : 8.61V
• Maximum Reverse Current : 3µa
• Package : SOD-323

1.5KE22A 5.0µA, DO-201AD Transient Voltage Suppressor Pack of 100

Specification:

• Minimum Breakdown voltage: 20.9V
• Maximum Breakdown voltage: 23.1V
• Maximum Reverse Leakage Current: 5.0µa
• Maximum peak pulse current: 49.0A
• Maximum clamping voltage: 30.6V
• Maximum Temperature Coefficient of VBR: 0.092%
• Power Dissipation: 1500W
• Package: DO-201AD

SMBJ7.5 600W Surface Mount Transient Voltage Suppressors Pack of 5pcs

Specification:-

1. Package : SMB/SMB(G)
2. Minimum Breakdown voltage : 8.33V
3. Maximum Breakdown voltage : 10.3V
4. Stand-off voltage : 7.5
5. Maximum reverse leakage current : 100
6. Maximum peak pulse current : 42.0A
7. Maximum clamping voltage : 14.3V
8. Power dissipation : 600W

MM3Z8B2 300mW ,SOD-323 Packaging Diodes Pack of 5pcs

Specification:

• Power Dissipation : 300mW
• Nominal Zener Voltage : 8.2V
• Minimum Zener voltage : 8.036V
• Maximum Zener voltage : 8.364V
• Maximum Reverse Current : 0.5µa
• Package : SOD-323

SMBJ6.5A 600W Surface Mount Transient Voltage Suppressors Pack of 5pcs

Specification:-

1. Package : SMB/SMB(G)
2. Minimum Breakdown voltage : 7.22V
3. Maximum Breakdown voltage : 7.98V
4. Stand-off voltage : 6.5
5. Maximum reverse leakage current : 500
6. Maximum peak pulse current : 53.6A
7. Maximum clamping voltage : 11.2V
8. Power dissipation : 600W

MM3Z5225B 300mW ,SOD-323 Packaging Diodes Pack of 5pcs

Specification:

• Power Dissipation : 300mW
• Nominal Zener Voltage : 3.0V
• Minimum Zener voltage : 2.85V
• Maximum Zener voltage : 3.15V
• Maximum Reverse Current : 50µa
• Package : SOD-323

SA60 1.0µA ,DO-15 Transient Voltage Suppressors Pack of 100

Specification:-

• Breakover voltage : Min(V) 66.7 , Max(V) 81.5
• Maximum peak current : 4.7A
• Maximum reverse leakage current @ VRWM : 1.0µA
• Power dissipation :500W
• Package : DO-15
