DIODE & ZENER

SMBJ26 600W Surface Mount Transient Voltage Suppressors Pack of 5pcs

Specification:-

1. Package : SMB/SMB(G)
2. Minimum Breakdown voltage : 28.9V
3. Maximum Breakdown voltage : 35.3V
4. Stand-off voltage : 26.0
5. Maximum reverse leakage current : 5.0
6. Maximum peak pulse current : 12.9A
7. Maximum clamping voltage : 46.6V
8. Power dissipation : 600W

P4KE30A 5.0µA ,DO-41 Transient Voltage Suppressors Pack of 100

Specification:-

• Breakover voltage : Min(V) 28.5 , Max(V) 31.5
• Maximum peak current : 10A
• Maximum reverse leakage current @ VRRM : 5.0µA
• Package : DO-41

1.5KE75A 5.0µA, DO-201AD Transient Voltage Suppressor Pack of 100

Specification:

• Minimum Breakdown voltage: 71.3V
• Maximum Breakdown voltage: 78.8V
• Maximum Reverse Leakage Current: 5.0µa
• Maximum peak pulse current: 14.6A
• Maximum clamping voltage: 103.0V
• Maximum Temperature Coefficient of VBR: 0.105%
• Power Dissipation: 1500W
• Package: DO-201AD

SMAJ90A 400W Surface Mount Transient Voltage Suppressors Pack of 5pcs

Specification:-

1. Package : SMA/SMA(G)
2. Minimum Breakdown voltage : 100.00V
3. Maximum Breakdown voltage : 111V
4. Stand-off voltage : 90.0
5. Maximum reverse leakage current : 5.0
6. Maximum peak pulse current : 2.1A
7. Maximum clamping voltage : 146.0V
8. Power dissipation : 400W

HER154 300V,DO-15 High Efficiency Rectifiers Pack of 5pcs

Specification:-

• Maximum repetitive peak reverse voltage : 300V
• Peak forward surge current 8.3ms single half sine- wave : 50A
• Maximum reverse current @ VRRM TA = 25°C : 5.0µA
• Maximum reverse recovery time : 50ns
• Package : DO-15

MM3Z6B2 300mW ,SOD-323 Packaging Diodes Pack of 5pcs

Specification:

• Power Dissipation : 300mW
• Nominal Zener Voltage : 6.2V
• Minimum Zener voltage : 6.076V
• Maximum Zener voltage : 6.324V
• Maximum Reverse Current : 1.0µa
• Package : SOD-323

MM1Z5235B 500mW SOD-123 Packaging Diodes Pack of 5pcs

Specification:

• Power Dissipation : 500mW
• Nominal Zener Voltage : 6.8V
• Minimum Zener voltage : 6.46V
• Maximum Zener voltage : 7.14V
• Maximum Reverse Current : 3µa
• Package : SOD-123

SMBJ7.5 600W Surface Mount Transient Voltage Suppressors Pack of 5pcs

Specification:-

1. Package : SMB/SMB(G)
2. Minimum Breakdown voltage : 8.33V
3. Maximum Breakdown voltage : 10.3V
4. Stand-off voltage : 7.5
5. Maximum reverse leakage current : 100
6. Maximum peak pulse current : 42.0A
7. Maximum clamping voltage : 14.3V
8. Power dissipation : 600W

SA150A 1.0µA ,DO-15 Transient Voltage Suppressors Pack of 100

Specification:-

• Breakover voltage : Min(V) 167 , Max(V) 185.0
• Maximum peak current : 2.1
• Maximum reverse leakage current @ VRWM : 1.0µA
• Power dissipation :500W
• Package : DO-15

1.5KE160A 5.0µA, DO-201AD Transient Voltage Suppressor Pack of 100

Specification:

• Minimum Breakdown voltage: 152.0V
• Maximum Breakdown voltage: 168.0V
• Maximum Reverse Leakage Current: 5.0µa
• Maximum peak pulse current: 6.8A
• Maximum clamping voltage: 219.0V
• Maximum Temperature Coefficient of VBR: 0.108%
• Power Dissipation: 1500W
• Package: DO-201AD

1.5KE16 5.0µA, DO-201AD Transient Voltage Suppressor Pack of 100

Specification:

• Minimum Breakdown voltage: 14.4V
• Maximum Breakdown voltage: 17.6V
• Maximum Reverse Leakage Current: 5.0µa
• Maximum peak pulse current: 64.0A
• Maximum clamping voltage: 23.5V
• Maximum Temperature Coefficient of VBR: 0.086%
• Power Dissipation: 1500W
• Package: DO-201AD

DO-41, FR105G 600V Glass Passivated Fast Recovery Rectifiers Diode pack of 5pcs

Specification

1. Case : DO-41
2. Maximum respective peak reverse voltage : 600v
3. Maximum average rectified current : 1.0A
4. Maxim reverse current : 5.0µA
5. Non-Repetitive Peak Forward Surge Current : 30A
6. Maxim forward voltage : 1.3V
7. Maximum reverse recovery time : 250ns
