DIODE & ZENER

SMC(G) SMCJ100A 1500W Surface Mount Transient Voltage Suppressors Pack of 5pcs

Specification

1. Case : SMC(G)
2. Stand-off voltage : 100.0V
3. Maximum peak pulse current : 9.3A
4. Maxim reverse current : 5.0µA
5. Maximum clamping voltage : 162V
6. Power dissipation : 1500W

SMC(G) SMCJ36 1500W Surface Mount Transient Voltage Suppressors Pack of 5pcs

Specification

1. Case : SMC(G)
2. Stand-off voltage : 36.0V
3. Maximum peak pulse current : 23.3A
4. Maxim reverse current : 5.0µA
5. Maximum clamping voltage : 64.3V
6. Power dissipation : 1500W

MM3Z2B4 300mW ,SOD-323 Packaging Diodes Pack of 5pcs

Specification:

• Power Dissipation : 300 mW
• Nominal Zener Voltage : 2.4V
• Minimum Zener voltage : 2.352V
• Maximum Zener voltage : 2.448V
• Maximum Reverse Current : 120µa
• Package : SOD-323

MM3Z5B1 300mW ,SOD-323 Packaging Diodes Pack of 5pcs

Specification:

• Power Dissipation : 300mW
• Nominal Zener Voltage : 5.0V
• Minimum Zener voltage : 4.998V
• Maximum Zener voltage : 5.202V
• Maximum Reverse Current : 2.0µa
• Package : SOD-323

SA14 1.0µA ,DO-15 Transient Voltage Suppressors Pack of 100

Specification:-

• Breakover voltage : Min(V) 15.6 , Max(V) 19.1
• Maximum peak current : 19.4A
• Maximum reverse leakage current @ VRWM : 1.0µA
• Power dissipation :500W
• Package : DO-15

5KP12A 10µA ,R-6 Transient Voltage Suppressor Pack of 100

Specification:

• Minimum Breakdown voltage: 13.3V
• Maximum Breakdown voltage: 14.7V
• Maximum Reverse Leakage Current: 10µa
• Maximum peak pulse current: 251A
• Maximum clamping voltage: 19.9V
• Power Dissipation: 5000W
• Package: R-6

P6KE33A 5.0µA, DO-15 Transient Voltage Suppressor Pack of 100

Specification:

• Minimum Breakdown voltage: 31.4V
• Maximum Breakdown voltage: 34.7V
• Maximum Reverse Leakage Current: 5.0µa
• Maximum peak pulse current: 13.2A
• Maximum clamping voltage: 45.7V
• Maximum Temperature Coefficient of VBR: 0.098%
• Power Dissipation: 600W
• Package: DO-15

1.5KE6.8 1000µA, DO-201AD Transient Voltage Suppressor Pack of 100

Specification:

1. Minimum Breakdown voltage: 6.12V
2. Maximum Breakdown voltage: 7.48V
3. Maximum Reverse Leakage Current: 1000µa
4. Maximum peak pulse current: 139A
5. Maximum clamping voltage: 10.8V
6. Maximum Temperature Coefficient of VBR: 0.057%
7. Power Dissipation: 1500W
8. Package: DO-201AD

SMBJ45 600W Surface Mount Transient Voltage Suppressors Pack of 5pcs

Specification:-

1. Package : SMB/SMB(G)
2. Minimum Breakdown voltage : 50.00V
3. Maximum Breakdown voltage : 61.1V
4. Stand-off voltage : 45.0
5. Maximum reverse leakage current : 5.0
6. Maximum peak pulse current : 7.5A
7. Maximum clamping voltage : 80.3V
8. Power dissipation : 600W

5KP10A 15µA ,R-6 Transient Voltage Suppressor Pack of 100

Specification:

• Minimum Breakdown voltage: 11.1V
• Maximum Breakdown voltage: 12.3V
• Maximum Reverse Leakage Current: 15µa
• Maximum peak pulse current: 294A
• Maximum clamping voltage: 17.0V
• Power Dissipation: 5000W
• Package: R-6

1.5KE120 5.0µA, DO-201AD Transient Voltage Suppressor Pack of 100

Specification:

• Minimum Breakdown voltage: 108.0V
• Maximum Breakdown voltage: 132.0V
• Maximum Reverse Leakage Current: 5.0µa
• Maximum peak pulse current: 8.7A
• Maximum clamping voltage: 173.0V
• Maximum Temperature Coefficient of VBR: 0.107%
• Power Dissipation: 1500W
• Package: DO-201AD

MM3ZB30 300mW ,SOD-323 Packaging Diodes Pack of 5pcs

Specification:

• Power Dissipation : 300mW
• Nominal Zener Voltage : 30V
• Minimum Zener voltage : 29.40V
• Maximum Zener voltage : 30.60V
• Maximum Reverse Current : 0.1µa
• Package : SOD-323
