DIODE & ZENER

DO-41, 1N4942G 200V Glass Passivated Fast Recovery Rectifiers Diode pack of 5pcs

Specification

1. Case : DO-41
2. Maximum respective peak reverse voltage : 200v
3. Maximum average rectified current : 1.0A
4. Maxim reverse current : 5.0µA
5. Non-Repetitive Peak Forward Surge Current : 30A
6. Maxim forward voltage : 1.3V
7. Maximum reverse recovery time : 150ns

SA20A 1.0µA ,DO-15 Transient Voltage Suppressors Pack of 100

Specification:-

• Breakover voltage : Min(V) 22.2 , Max(V) 24.5
• Maximum peak current : 15.4A
• Maximum reverse leakage current @ VRWM : 1.0µA
• Power dissipation :500W
• Package : DO-15

SMB(G), ER3G 400V Surface Mount Fast Recovery Rectifiers Diode pack of 5pcs

Specification

1. Case : SMB(G)
2. Maximum respective peak reverse voltage : 400v
3. Maximum average rectified current : 3.0A
4. Maxim reverse current : 10.0µA
5. Non-Repetitive Peak Forward Surge Current : 100A
6. Maxim forward voltage : 1.25V

MM3Z5231B 300mW ,SOD-323 Packaging Diodes Pack of 5pcs

Specification:

• Power Dissipation : 300mW
• Nominal Zener Voltage : 5.1V
• Minimum Zener voltage : 4.85V
• Maximum Zener voltage : 5.36V
• Maximum Reverse Current : 5µa
• Package : SOD-323

1.5KE9.1 50µA, DO-201AD Transient Voltage Suppressor Pack of 100

Specification:

1. Minimum Breakdown voltage: 8.19V
2. Maximum Breakdown voltage: 10.0V
3. Maximum Reverse Leakage Current: 50µa
4. Maximum peak pulse current: 109A
5. Maximum clamping voltage: 13.8V
6. Maximum Temperature Coefficient of VBR: 0.068%
7. Power Dissipation: 1500W
8. Package: DO-201AD

1.5KE170 5.0µA, DO-201AD Transient Voltage Suppressor Pack of 100

Specification:

• Minimum Breakdown voltage: 153.0V
• Maximum Breakdown voltage: 187.0V
• Maximum Reverse Leakage Current: 5.0µa
• Maximum peak pulse current: 6.2A
• Maximum clamping voltage: 244.0V
• Maximum Temperature Coefficient of VBR: 0.108%
• Power Dissipation: 1500W
• Package: DO-201AD

1.5KE160 5.0µA, DO-201AD Transient Voltage Suppressor Pack of 100

Specification:

• Minimum Breakdown voltage: 144.0V
• Maximum Breakdown voltage: 176.0V
• Maximum Reverse Leakage Current: 5.0µa
• Maximum peak pulse current: 6.5A
• Maximum clamping voltage: 230.0V
• Maximum Temperature Coefficient of VBR: 0.108%
• Power Dissipation: 1500W
• Package: DO-201AD

P6KE220A 5.0µA, DO-15 Transient Voltage Suppressor Pack of 100

Specification:

• Minimum Breakdown voltage: 209.0V
• Maximum Breakdown voltage: 231.0V
• Maximum Reverse Leakage Current: 5.0µa
• Maximum peak pulse current: 1.83A
• Maximum clamping voltage: 328.0V
• Maximum Temperature Coefficient of VBR: 0.108%
• Power Dissipation: 600W
• Package: DO-15

SMA(G), ER2G 400V Surface Mount Fast Recovery Rectifiers Diode pack of 5pcs

Specification

1. Case : SMA(G)
2. Maximum respective peak reverse voltage : 400v
3. Maximum average rectified current : 2.0A
4. Maxim reverse current : 0.5µA
5. Non-Repetitive Peak Forward Surge Current : 50A
6. Maxim forward voltage : 1.25V

SMBJ30 600W Surface Mount Transient Voltage Suppressors Pack of 5pcs

Specification:-

1. Package : SMB/SMB(G)
2. Minimum Breakdown voltage : 33.3V
3. Maximum Breakdown voltage : 40.7V
4. Stand-off voltage : 30.0
5. Maximum reverse leakage current : 5.0
6. Maximum peak pulse current : 11.2A
7. Maximum clamping voltage : 53.5V
8. Power dissipation : 600W

DO-41, 1N4944G 400V Glass Passivated Fast Recovery Rectifiers Diode pack of 5pcs

Specification

1. Case : DO-41
2. Maximum respective peak reverse voltage : 400v
3. Maximum average rectified current : 1.0A
4. Maxim reverse current : 5.0µA
5. Non-Repetitive Peak Forward Surge Current : 30A
6. Maxim forward voltage : 1.3V
7. Maximum reverse recovery time : 150ns

P6KE100A 5.0µA, DO-15 Transient Voltage Suppressor Pack of 100

Specification:

• Minimum Breakdown voltage: 95.0V
• Maximum Breakdown voltage: 105.0V
• Maximum Reverse Leakage Current: 5.0µa
• Maximum peak pulse current: 4.4A
• Maximum clamping voltage: 137.0V
• Maximum Temperature Coefficient of VBR: 0.106%
• Power Dissipation: 600W
• Package: DO-15
