SMD LED

2835 Bright Red color 0.2W High power SMD LED's box of 4000 pcs

Specification

1. Power rating : 0.2Watt
2. Dimensions : 2.8mm x 3.5mm (L x B)
3. Max. Drive current range : 60mA to 150mA
4. LED junction temperature : 125°C
5. Soldering temperature : 260°C for max. 10 seconds

5730 Bright Blue color 0.5W 3V High power SMD LED's box of 4000 pcs

Specification

1. Operating voltage range: 3V to 4V
2. Emerging color: Blue
3. Power rating : 0.5Watt
4. Dimensions : 5.7mm x 3.0mm (L x B)
5. Max. Drive current range : 60mA to 150mA
6. LED junction temperature : 105°C
7. Soldering temperature : 260°C for max. 10 seconds

5054 Bright white color 1W 12V High power 3 SMD LED module pack of 20pcs

Specification

1. Operating voltage range: 5V to 15V
2. Recommended voltage: 12V
3. Emerging color : White
4. Power rating : 1Watt
5. Dimensions of LED : 5mm x 5.4mm (L x B)
6. Max. Drive current range : 60mA to 150mA
7. LED junction temperature : 125°C

5730 Bright Blue color 0.5W 3V High power SMD LED pack of 50 pcs

Specification

1. Operating voltage range : 3V to 4V
2. Emerging color : Blue
3. Power rating : 0.5Watt
4. Dimensions : 5.7mm x 3.0mm (L x B)
5. Max. Drive current range : 60mA to 150mA
6. LED junction temperature : 105°C
7. Soldering temperature : 260°C for max. 10 seconds

2835 Bright Blue color 0.2W 3V High power SMD LED pack of 500 pcs

Specification

1. Operating voltage range: 2.5V to 3.2V
2. Emerging color: Blue
3. Power rating : 0.2Watt
4. Dimensions : 2.8mm x 3.5mm (L x B)
5. Max. Drive current range : 60mA to 150mA
6. LED junction temperature : 125°C
7. Soldering temperature : 260°C for max. 10 seconds

2835 Bright Blue color 0.2W 3V High power SMD LED's box of 4000 pcs

Specification

1. Operating voltage range : 2.5V to 3.2V
2. Emerging color : Blue
3. Power rating : 0.2Watt
4. Dimensions : 2.8mm x 3.5mm (L x B)
5. Max. Drive current range : 60mA to 150mA
6. LED junction temperature : 125°C
7. Soldering temperature : 260°C for max. 10 seconds

2835 Warm White 0.2W High power SMD LED Pack of 500

Specification:-

• Operating voltage: 3.0 - 3.1V
• Power rating : 0.2Watt
• Dimensions : 2.8mm x 3.5mm (L x B)
• Max. Drive current range : 60mA to 150mA
• LED junction temperature : 125°C
• Soldering temperature : 260°C for max. 10 seconds

5050 Bright Red color 0.2W High power's SMD LED's box of 1000pcs

Specification

1. Emerging color : red
2. Power rating : 0.2Watt
3. Dimensions : 5mm x 5mm (L x B)
4. Max. Drive current range : 60mA to 150mA
5. LED junction temperature : 125°C
6. Soldering temperature : 260°C for max. 10 seconds

WS2812B 5050 RGB Addressable SMD Pixel LED Chip 5V DC Pack of 100

Specification:-

• Color: RGB
• Shape: Rectangular
• Dimension: 5x5mm
• Operating Voltage: 3.0V
• Type: SMD5050

2835 Bright white color 0.5W 12V High power 2 SMD LED modules pack of 200pcs

Specification

1. Operating voltage range: 5V to 12V
2. Emerging color: White
3. Power rating : 0.5Watt
4. Dimensions of LED : 2.8mm x 3.5mm (L x B)
5. Max. Drive current range : 60mA to 150mA
6. LED junction temperature : 125°C

5730 Bright Red color 0.5W 3V High power SMD LED's box of 4000 pcs

Specification

1. Operating voltage range: 3V to 4V
2. Emerging color: red
3. Power rating : 0.5Watt
4. Dimensions : 5.7mm x 3.0mm (L x B)
5. Max. Drive current range : 60mA to 150mA
6. LED junction temperature : 105°C
7. Soldering temperature : 260°C for max. 10 seconds

5730 Bright Blue color 0.5W 3V High power SMD LED pack of 500 pcs

Specification

1. Operating voltage range: 3V to 4V
2. Emerging color: Blue
3. Power rating : 0.5Watt
4. Dimensions : 5.7mm x 3.0mm (L x B)
5. Max. Drive current range : 60mA to 150mA
6. LED junction temperature : 105°C
7. Soldering temperature : 260°C for max. 10 seconds
