BMS (Battery Management System)
Showing 1–12 of 367 results
.jpg)
.jpg)
 (2).jpg)
 SMART BMS 100A (R24TK1A) 4-8S.jpg)
.jpg)
.jpg)
.jpg)
.jpg)
.jpg)
.jpg)
.jpg)
-
![Smart Active Balance BMS 16S 100A (JK-PB1A16S10P)]()
Smart Active Balance BMS 16S 100A (JK-PB1A16S10P)
Rs. 8219.00Specification:-
- Cell specifications: 16 Strings Lifepo4/Li-ion/LTO
- Interface type: Charge and discharge are both at the same port
- Work-temperature: -30~70 °C
- Storage temperature: -30~70 °C
- Work-humidity: 10~80 %RH
- Storage humidity: 10~85 %RH
- Power Supply: 20~70 V
- Working consumption: 19 mA @ 58 V
- standby consumption: 200 uA @ 58 V
- Model No.(81c5)
-
![4S 80A BMS LFP Hardware Waterproof]()
4S 80A BMS LFP Hardware Waterproof
Rs. 2289.00Specification:-
- Battery Configuration: 4S for LiFePO4 (LFP) batteries
- Continuous Discharge Current: 80A
- Continuous Charge Current: 40A
- Over-Voltage Protection: 3.75±0.05V
- Balancing Current: 30±5mA
- Charge Voltage: 14.6V
- Working Temp: -20~70 °C
- Working current: 500 uA
- Model no. (1199)
-
![8S 1A Li-Ion/LiFePO4 Hardware Active Balancer]()
8S 1A Li-Ion/LiFePO4 Hardware Active Balancer
Rs. 1239.00Specification:-
- Software active equalization
- Number of battery pack strings - 8S
- Balance current ≤1A
- Balance mode - Active equilibrium
- working temperature: -20°C~60°C
- Model no. (48eb)
-
![4S 50A BMS LFP Hardware Waterproof]()
4S 50A BMS LFP Hardware Waterproof
Rs. 979.00Specification:-
- Battery Configuration: 4S for LiFePO4 (LFP) batteries
- Continuous Discharge Current: 50A
- Continuous Charge Current: 25A
- Over-Voltage Protection: 3.75±0.05V
- Balancing Current: 30±5mA
- Charge Voltage: 14.6V
- Working current: 100 uA
- Working Temp: -20~70 °C
- Model no. (11b4)
-
![4-8S 100A Smart Active Balance Li-Ion-LiFePO4 BMS (R24TK1A)]()
4-8S 100A Smart Active Balance Li-Ion-LiFePO4 BMS (R24TK1A)
Rs. 6059.00Specification:-
- Model Number: R24TK1A (7639)
- Cell sampling voltage range: 1.5V-4.9V
- Operating voltage range: >10V
- Balance method: Active Balance
- Working power consumption: ≤1.25W
- working temperature: -40°C~85°C
-
![Smart BMS LiFePO4 4S 12V 100A Common Port with Balance]()
Smart BMS LiFePO4 4S 12V 100A Common Port with Balance
Rs. 4109.00Specification:-
- Battery Configuration: Smart BMS LiFePO4 4S 12V 100A
- Continuous Discharge Current: 100A
- Over-Voltage Protection: 3.8V
- Charge Current: 50A
- Charge Voltage: 14.6V
- Model no. (21a6)
-
![4S 60A BMS LFP Hardware Waterproof]()
4S 60A BMS LFP Hardware Waterproof
Rs. 1269.00Specification:-
- Battery Configuration: 4S for LiFePO4 (LFP) batteries
- Continuous Discharge Current: 60A
- Continuous Charge Current: 30A
- Over-Voltage Protection: 3.75±0.05V
- Balancing Current: 30±5mA
- Charge Voltage: 14.6V
- Working current: 100 uA
- Working Temp: -20~70 °C
- Model no. (1185)
-
![Smart BMS LiFePO4 38S 120V 100A Common Port with Balance]()
Smart BMS LiFePO4 38S 120V 100A Common Port with Balance
Rs. 26769.00Specification:-
- Battery Configuration: Smart BMS LiFePO4 38S 120V 100A
- Continuous Discharge Current: 100A
- Over-Voltage Protection: 3.8V
- Charge Current: 50A
- Charge Voltage: 120V
- Model no. (7633)
-
![Smart BMS LiFePO4 24S 72V 50A Common Port with Balance]()
Smart BMS LiFePO4 24S 72V 50A Common Port with Balance
Rs. 6239.00Specification:-
- Battery Configuration: Smart BMS LiFePO4 24S 72V 50A
- Continuous Discharge Current: 50A
- Over-Voltage Protection: 3.8V
- Charge Current: 25A
- Charge Voltage: 87.6V
- Model no. (46cb)
-
![16S 60A BMS LFP Hardware Waterproof]()
16S 60A BMS LFP Hardware Waterproof
Rs. 2059.00Specification:-
- Battery Configuration: 16S for LiFePO4 (LFP) batteries
- Continuous Discharge Current: 60A
- Over-Voltage Protection: 3.8V
- Balancing Current: 50mA
- Charge Voltage: 58.4V
- Model no. (10cb)
-
![Smart BMS 3-4S 100A Same Port for Charge and Discharge (DP04S014)]()
Smart BMS 3-4S 100A Same Port for Charge and Discharge (DP04S014)
Rs. 2479.00Specification:-
- Cell specifications: 3~4 strings of LiFePO4 battery
- Continuous current: 100A
- Balance detect Voltage 3.8
- Interface type: Charge and discharge are both at the same port
- Charging voltage: 3.6V*Number of strings
- Cell voltage range: 2.30~3.75V
- Continuous charging current: 100A
- Continuous discharging current: 100A
- Model No.(73bb)
-
![8S 100AMP LFP BMS Hardware (ZP10S036)]()
8S 100AMP LFP BMS Hardware (ZP10S036)
Rs. 500.00Specification:-
- Model: ZP10S036
- Charging voltage: 3.6V Number of strings
- Cell voltage range: 2.0~3.75V
- Continuous charging current: 50A
- Continuous discharging current: 100A
- Consumption of running: ≤100uA
- -Circuit resistance: ≤20mR
- Operating temperature: -20°C-75°C
- Model no. (76b9)
