CONNECTORS

Double L shape 90 degree angle Male Berg Strip 1 x 40 Pin headers pack of 100 sticks

Specifications

1. Number of pins: 40 pin
2. Spacing(pitch): 2.54 mm
3. Strip length: 10 cm ( approx.)
4. Pin type: L shape (90° angle) both
5. Package includes: 100 male berg strips (40 pins each)

PCT-111 Quick Connection 250V/6A Terminal Block Wire Connector

Specification:-

• Model: PCT-111
• Rated voltage: 250V
• Rated current: 24A
• Wire diameter: 0.5-2.5mm²
• Voltage resistance: 4kV
• Ambient temperature: -40℃~+105℃
• Strip length: 10-11mm

9V battery clip connector with 3.5mm pin jacks pack of 50pcs

Specifications

1. Working voltage: 9V
2. Power rating: 1A
3. Wire color : Red and Black
4. Made from soft leather
5. Environmental friendly
6. Length of the wire : 6cm
7. Pin size : 3.5mm

2EDGK-5.08-3P 3 hole 5.08mm pitch Pluggable Female terminal block connector pack of 5pcs

Specification

1. Body material  :  Nylon 66
2. Screw material  :  phosphor bronze
3. Pitch spacing  :  5.08mm
4. Number of holes  :  3
5. Type of connector  :  Female pluggable
6. Rated voltage  :  320V
7. Current rating  :  20A
8. Package contains  :  5 pieces of female connectors

HM-PCT-223-3 Pole Terminal Block 450V/32A Wire Quick Connector

Specification:-

• Model: HM-PCT-223-3P
• Rated voltage: 450V
• Rated current: 32A
• Wire diameter: 0.5-4mm2
• Voltage resistance: 4kV
• Ambient temperature: -40℃~+105℃
• Strip length: 11-12mm
• The number of poles: 3P

2 Pin Wire-To-Board Female Relimate Connector with wire

Specification

• Current rating: 3A AC/DC.
• Voltage ratio: 24V AC/DC.
• Temperature range: -25℃ to +85 ℃
• Material: copper-tin
• Contact resistance: 10mΩ Max.
• Insulation resistance: 1000MΩ
• MinApplicable wire sizes: AWG 28

Mini jumper short circuit cap connectors pack of 2000pcs

Specification

1. Voltage rating : Up to 240V
2. Current range : 2A to 5A
3. Insulation material : Nylon hard plastic
4. Contacting Material : Beryllium copper
5. Plating : Gold flash overall
6. Dual-beam contacts
7. Smart design

E7508 20A Grey color 20 AWG wire gauge hard nylon insulated Ferrule wire crimp connector pack of 50pcs

Specifications

1. 100% Genuine and new product
2. Type  :  Ferrule crimp connector
3. Wire gauge  :  20 AWG
4. Voltage rating  :  300V to 600V
5. Highly insulated
6. Tin plated body
7. Good conductor of electricity
8. Easy to connect

Mono 3.5mm male to 6.35mm female Golden color audio connector pack of 5pcs

Specification

1. 100% branded and new product
2. Mono plug 3.5mm male to 6.35mm female golden color
3. Contact material  :  high quality copper
4. Prevent data fluctuation
5. High carbon steel body with silver plating
6. Hard plastic insulation on top and inside

Male and Female pair of 4 pin 5.08mm pitch pluggable terminal block connectors pack of 10 pair (2EDGR-5.08-4P and 2EDGK-5.08-4P)

Specification

1. Body material  :  Nylon 66
2. Metal use  :  phosphor bronze
3. Pitch spacing  :  5.08mm ( both )
4. Number of holes and pins  :  4
5. Type of connector  :  Pluggable terminal block
6. Rated voltage  :  320V
7. Current rating  :  20A
8. Package contains  :  10 pairs (10 pieces of male + 10 pieces of female)

4mm 10A 9 leaf Black color Male plug banana connector pack of 5pcs

Specification

1. Type : Male plug banana connector
2. Current rating : 10A
3. Voltage rating : 30V
4. Contact material : copper
5. Number of leaf or spring : 9
6. Nickel plating
7. Highly insulated with polyethylene
8. Larger contact surface for better performance

4mm 30A Red color Female socket banana connectors pack of 10pcs

Specification

1. Type : Female socket banana connector
2. Current rating : 30A
3. Voltage rating : 30V
4. Contact material : copper
5. Nickel plating
6. Highly insulated with polyethylene material
7. Larger contact surface for better and stable performance
