CONNECTORS

2EDGK-5.08-5P 5 hole 5.08mm pitch Pluggable Female terminal block connectors pack of 50pcs

Specification

1. Body material  :  Nylon 66
2. Screw material  :  phosphor bronze
3. Pitch spacing  :  5.08mm
4. Number of holes  :  5
5. Type of connector  :  Female pluggable
6. Rated voltage  :  320V
7. Current rating  :  20A
8. Package contains  :  50 pieces of female connectors

GX16 Female 5 hole 5A metal aviation connectors pack of 50pcs

Specification

1. Connector type  :  GX16 Female
2. Number of hole  :  5
3. Working voltage range  :  200V to 250V
4. Rated current  :  5A
5. Coupling type  :  thread
6. Contact material  :  copper
7. Metal body with nickel plating
8. Robust

7 pin XH JST female wires connectors 2.5mm pitch 2515 series pack of 1000pcs

Specification

1. XH series JST female connector
2. Number of pin or wire holes : 7
3. Current rating : 3A
4. Voltage rating : 250V
5. Temperature range : -25°C to +85°C
6. Original folded beam contact
7. Box shape shrouded header
8. Interchangeability

2EDGR-5.08-7P 7 pin 5.08mm pitch Pluggable Male terminal block connectors pack of 50pcs

Specification

1. Body material:  Nylon 66
2. Pin material:  phosphor bronze
3. Pitch spacing  :  5.08mm
4. Number of pin  :  7
5. Type of connector  :  Male pluggable
6. Rated voltage  :  320V
7. Current rating  :  20A
8. Package contains  :  50 pieces of male connectors

6 pin XH JST female wires connectors 2.5mm pitch 2515 series pack of 1000pcs

Specification

1. XH series JST female connector
2. Number of pin or wire holes : 6
3. Current rating : 3A
4. Voltage rating : 250V
5. Temperature range : -25°C to +85°C
6. Original folded beam contact
7. Box shape shrouded header
8. Interchangeability

HM-LT-03-12 Terminal Block Splice 250V/32A Quick Connector

Specification:-

• Model: HM-LT-03-12
• Rated voltage: 250V
• Rated current: 32A
• Wire diameter: 0.5-4mm²
• Voltage resistance: 4kV
• Ambient temperature: -40℃~+105℃
• Strip length: 11-12mm

LT-TB 1x2 Multi-in and Multi-out 450V/32A Wire Splitter Rail Terminal Connector

Specification:-

• Model: LT-TB1x2
• Rated voltage: 450V
• Rated current: 32A
• Wire diameter: 0.5-4mm²
• Voltage resistance: 4kV
• Ambient temperature: -40℃~+105℃
• Strip length: 11-12mm
• The number of poles: 2P

2-Way 60A Bakelite Heavy Duty Connector Strip Screw Terminal Red Color

Specification:-

• Current Rating: 60 Amps
• Connector Type: Screw
• Material: Bakelite
• Type: Bakelite Connector Strip
• Color: Red
• Easy Installation
• High Current Capacity

2EDGR-5.08-8P 8 pin 5.08mm pitch Pluggable Male terminal block connectors pack of 50pcs

Specification

1. Body material:  Nylon 66
2. Pin material:  phosphor bronze
3. Pitch spacing  :  5.08mm
4. Number of pin  : 8
5. Type of connector  :  Male pluggable
6. Rated voltage  :  320V
7. Current rating  :  20A
8. Package contains  :  50 pieces of male connectors

GX16 Male 6 pin 5A metal aviation connectors pack of 50pcs

Specification

1. Connector type  :  GX16 Male
2. Number of pins  :  6
3. Working voltage range  :  200V to 250V
4. Rated current  :  5A
5. Coupling type  :  thread
6. Contact material  :  copper
7. Metal body with nickel plating
8. Robust

2EDGK-5.08-7P 7 hole 5.08mm pitch Pluggable Female terminal block connectors pack of 20pcs

Specification

1. Body material  :  Nylon 66
2. Screw material  :  phosphor bronze
3. Pitch spacing  :  5.08mm
4. Number of holes  :  7
5. Type of connector  :  Female pluggable
6. Rated voltage  :  320V
7. Current rating  :  20A
8. Package contains  :  20 pieces of female connectors

5 pin XH JST female wires connectors 2.5mm pitch 2515 series pack of 1000pcs

Specification

1. XH series JST female connector
2. Number of pin or wire holes : 5
3. Current rating : 3A
4. Voltage rating : 250V
5. Temperature range : -25°C to +85°C
6. Original folded beam contact
7. Box shape shrouded header
8. Interchangeability
