METAL PUSH BUTTON
Showing 1–12 of 218 results
-
![16mm Momentary Push Button Switch – Flat Head, 1NO, Red Ring LED, Nickel-Plated Brass, IP65, 12V]()
16mm Momentary Push Button Switch – Flat Head, 1NO, Red Ring LED, Nickel-Plated Brass, IP65, 12V
Rs. 299.00Specification:-
- Model: HBDGQ16F-10E/J/N/12V/R
- Mounting Hole Size: 16mm
- LED Lamp: Red
- Head Style: Flat head
- Function: Momentary
- Contact Type: 1NO (Normally Open)
- Material: Nickel-plated brass
- Ingress Protection: IP65
- Terminal Type: Pin terminal
-
![220V 19mm Push Button Switch – Blue Ring LED Indicator | Stainless Steel | IP67]()
220V 19mm Push Button Switch – Blue Ring LED Indicator | Stainless Steel | IP67
Rs. 549.00Specification:-
- Model no. HBDS1-AGQ19F-11EZ/J/N/220V/B
- Voltage: 220V AC
- Size: 19mm panel mount
- LED Lamp: Blue
- Waterproof: IP65/IP67
- Terminals: Pin terminal
- Material: Stainless steel metal body
- Durable and Waterproof Design
-
![24V 19mm Emergency Stop Plastic Switch – Aluminum Alloy Head | Red head with “STOP” | 1NO1NC | Pin Terminal | IP67]()
24V 19mm Emergency Stop Plastic Switch – Aluminum Alloy Head | Red head with “STOP” | 1NO1NC | Pin Terminal | IP67
Rs. 859.00Specification:-
- Model no. HBDS1-AGQ19F-11DTSC/J/S2/R/24V/G
- Mounting holes: 16mm
- LED Lamp: Green
- Ingress Protection: IP67
- Terminals: Pin terminal
- 1NO 1NC contact configuration
-
![22mm Emergency Stop Switch | 2NC | Latching | IP65 | 40mm Red Plastic Head | Quick Assembly]()
22mm Emergency Stop Switch | 2NC | Latching | IP65 | 40mm Red Plastic Head | Quick Assembly
Rs. 319.00Specification:-
- Model no. HBDY5-KA-02TS/R/201
- Waterproof: IP65
- 22mm panel mount size
- 40mm red flat head
- Durable and Waterproof Design
- 2NC contacts for dual circuit safety integration
-
![16mm Micro Travel Push Button Switch – Flat Head, Green Ring LED, 1NO, Momentary, Stainless Steel, IP67, 220V]()
16mm Micro Travel Push Button Switch – Flat Head, Green Ring LED, 1NO, Momentary, Stainless Steel, IP67, 220V
Rs. 469.00Specification:-
- Model no. HBDS1-AGQ16F- 11E/J/N/220V/G
- LED Type: GREEN Ring LED – 220V DC
- Mounting holes: 16mm
- Action Type: Momentary (press-to-activate)
- Contact Type: 1NO (Normally Open)
- Material: Stainless steel body for durability
- Ingress Protection: IP67
- Terminals: 5 Pin terminal
-
![220V 19mm Push Button Switch – White Ring LED Indicator | Stainless Steel | IP67]()
220V 19mm Push Button Switch – White Ring LED Indicator | Stainless Steel | IP67
Rs. 549.00Specification:-
- Model no. HBDS1-AGQ19F-11EZ/J/N/220V/W
- Voltage: 220V AC
- Size: 19mm panel mount
- LED Lamp: White
- Waterproof: IP65/IP67
- Terminals: Pin terminal
- Material: Stainless steel metal body
- Durable and Waterproof Design
-
![220V 16mm Push Button Switch – Flat Head | White Ring LED | Nickel-Plated Brass | IP67]()
220V 16mm Push Button Switch – Flat Head | White Ring LED | Nickel-Plated Brass | IP67
Rs. 519.00Specification:-
- Model no. HBDS1-AGQ16F-11EZ/J/N/220V/W
- LED Indicator: White Ring LED – 220V
- Mounting holes: 16mm
- Action Type: Momentary (press-to-activate)
- Contact Type: 1NO (Normally Open)
- Material: Stainless steel body for durability
- Ingress Protection: IP65/IP67
- Terminals: Pin terminal
-
![16mm Momentary Push Button Switch – High Head, 1NO, Nickel-Plated Brass, IP65]()
16mm Momentary Push Button Switch – High Head, 1NO, Nickel-Plated Brass, IP65
Rs. 179.00Specification:-
- Model: HBDGQ16H-10/J/N
- Mounting Hole Size: 16mm
- Head Style: Flat head
- Function: Momentary
- Contact Type: 1NO (Normally Open)
- Material: Nickel-plated brass
- Ingress Protection: IP65
- Terminal Type: Pin terminal
-
![22mm Emergency Stop Switch – Flat Red Head | 1NO1NC | Without LED | Pin Terminal | IP67]()
22mm Emergency Stop Switch – Flat Red Head | 1NO1NC | Without LED | Pin Terminal | IP67
Rs. 786.00Specification:-
- Model no. HBDS1-AGQ22F-11TSC/J/S2/R
- Size: 19mm panel mount
- Color: Red
- Waterproof: IP67
- Terminals: Pin terminal
- Material: Durable metal alloy
- Durable and Waterproof Design
-
![16mm Push Button Switch – Flat Head, 1NO1NC, Green Ring LED, Momentary, Nickel-Plated Brass, IP67, 24V]()
16mm Push Button Switch – Flat Head, 1NO1NC, Green Ring LED, Momentary, Nickel-Plated Brass, IP67, 24V
Rs. 429.00Specification:-
- Model no. HBDS1-AGQ16F-11E/J/N/24V/G
- LED Indicator: Green Ring LED – 24V
- Mounting holes: 16mm
- Action Type: Momentary (press-to-activate)
- Contact Type: 1NO (Normally Open)
- Material: Stainless steel body for durability
- Ingress Protection: IP65/IP67
- Terminals: Pin terminal
-
![12mm Momentary Push Button Switch – Blue Domed Head with Horn Symbol, 1NO, Zinc Alloy, IP65]()
12mm Momentary Push Button Switch – Blue Domed Head with Horn Symbol, 1NO, Zinc Alloy, IP65
Rs. 259.00Specification:-
- Model: HBDGQ12B-10/L/A/B/UV-Horn
- Mounting Hole Size: 12mm
- Contact Type: 1NO (Normally Open)
- Blue Domed Head with Horn Symbol: Clear function indication
- Operation: Momentary – circuit active only while pressed
- Body Material: Zinc aluminum alloy for strength and durability
- Protection Rating: IP65 – dustproof and water-resistant
- Screw Terminals: Easy, secure, solder-free wiring
-
![24V 19mm Push Button Switch – Blue Ring LED Indicator | Stainless Steel | IP67]()
24V 19mm Push Button Switch – Blue Ring LED Indicator | Stainless Steel | IP67
Rs. 549.00Specification:-
- Model no. HBDS1-AGQ19F-11EZ/J/N/24V/B
- Voltage: 24V AC
- Size: 19mm panel mount
- LED Color: Blue Ring Indicator
- Waterproof: IP65/IP67
- Terminals: Pin terminal
- Material: Stainless steel metal body
- Durable and Waterproof Design
Frequently Asked Questions
Yes! Our collection includes Mini WiFi Smart Switch Modules that support app and voice control, making them perfect for smart home automation. Additionally, push button and toggle switches are widely used in DIY electronics, robotics, and educational projects.
Yes. Many of our switches come with built‑in LED indicators (blue, green, yellow, white) for Easy status monitoring. These are Especially useful in control panels, machinery, and DIY electronics projects where visibility matters.
We stock nickel‑plated brass push button switches (IP65 rated) and high‑current toggle switches that are suitable for industrial control panels, machinery, and automotive applications. For heavy loads, always check the voltage and current rating before installation.
Consider these factors :
- Type of operation (momentary vs self‑lock)
- Size & mounting hole (12mm, 16mm, 19mm)
- Current & voltage rating (AC 125V 3A, AC 250V 1.5A, etc.)
- Indicator requirement (LED or non‑LED)
- Application (DIY, home automation, industrial use)
Our filters and product Descriptions make it Easy to select the right switch.
. SPST (Single Pole Single Throw): Simple ON/OFF switch.
. SPDT (Single Pole Double Throw): One input, two outputs – used for selecting between two circuits.
DPDT (Double Pole Double Throw) : Controls two separate circuits simultaneously, often used in motor direction control
