0.0010μF 102J 250V CBB18 Polypropylene Film Capacitor Pack of 5pcs
Specification:-
- Rated voltage : 250V
- Dimensions = 14.0mm(W)
- Dimensions = 11.0mm(H)
- Dimensions = 7.0mm(T)
- Dimensions = 7.5mm(P)
- Dimensions = 0.5(d)
- Standard = GB10188 (IEC384-13)
- Climatic Category = 40/085/21
- Dissipation Factor = ≤ 0.0008 (20°C, 1KHz)
SKU: DP8533E
0.0010μF 102J 250V CBB18 Polypropylene Film Capacitor Pack of 5pcs
Polypropylene Film Capacitors, CBB18. Excellent high-frequency insulation performance allows capacitance and loss to be frequency independent over a wide frequency range with minor temperature changes, which is challenging for conventional dielectric materials to achieve. High thermal stability and low absorption coefficient. The best choice for high-frequency, large-current circuits, and S-shaping correction in TVs widely used in pulse, DC, high voltage, and high frequency circuits. High frequency and high pulse rise time circuit supplies are used in electronic lighting ballasts and high voltage power sources. This product is an excellent illustration of a product with a straightforward design that does its function admirably. The polypropylene film used to make this capacitor is a good electrical conductor.
Features:
- High reliability
- Self-healing property
- Feature radial leads
- Dip through hole mounting
- Best Quality Product
