Specification:-
- Case type : 0805
- Capacitance : 0.1uf
- Tolerance : ± 10%
- Voltage range : 50V
- Mounting Type : SMD
- Operating Temperature Range (°C) : -55 °C to +125 °C
SKU: RO8559A
0.1uf 0805 50V (104) SMD Capacitor Pack of 50
The 0.1µF 0805 50V (104) SMD capacitor is a surface-mount ceramic capacitor widely used in electronic circuits for decoupling, filtering, and timing applications. Its compact 0805 package (measuring 0.08 x 0.05 inches or 2.0 x 1.25 mm) makes it suitable for modern high-density PCB designs where space-saving components are essential. With a capacitance value of 0.1 microfarad (µF), labeled as 104 (which stands for 10 followed by four zeros in picofarads, i.e., 100,000 pF = 0.1 µF), it effectively filters out high-frequency noise in both analog and digital circuits. Rated at 50 volts, this capacitor can be safely used in circuits with operating voltages well below this threshold, offering a margin of safety against voltage spikes or surges. Constructed from multi-layer ceramic dielectric (typically X7R or NP0/C0G), it provides stable performance over a range of temperatures and frequencies. SMD capacitors like this one are soldered directly onto the PCB surface, making them ideal for automated assembly processes in commercial and industrial applications.
Applications:-
- Power supply filtering and decoupling
- Signal coupling and blocking
- Timing circuits and oscillators
- Voltage regulation and smoothing
- Audio amplifiers and signal processing
