1N4448 100V ,DO-34/DO-35 High Speed Switching Diodes Pack of 5pcs
Specification:-
- Maximum repetitive peak reverse voltage : 100V
- Maximum average rectified current : 150mA
- Maximum reverse recovery time : 4.0ns
- Power dissipation : 500mW
- Package : DO-34/DO-35
SKU: 675JUN
1N4448 100V ,DO-34/DO-35 High Speed Switching Diodes Pack of 5pcs
A diode is a component with two terminals that permits electricity to flow from the anode to the cathode only in one direction. In this instance, a grey bar can be used to identify the cathode terminal.1N4448 diodes are referred to as switching diodes since its primary function is in rapid switching. These diodes act primarily in the same way as a typical switch. When the voltage is fixed, these diodes have a high resistance; when the voltage is increased, their resistance decreases. It is widely utilized in a variety of switches with rapid operation for switching, high-speed rectification, home and telecommunications industry protection, etc.
FEATURES:-
- Fast Switching Speed
- General Purpose Rectification
- Low power loss, high efficiency
- Ideal for automated placement
- High surge current capability
