1N4934 100V ,DO-41 Fast Recovery Rectifiers Pack of 5pcs
Specification:-
- Maximum repetitive peak reverse voltage : 100V
- Peak forward surge current 8.3ms single half sine- wave : 30A
- Maximum reverse current @ VRRM TA = 25°C : 5.0µA
- Maximum reverse recovery time : 200ns
- Package : DO-41
SKU: 3232SREP
1N4934 100V ,DO-41 Fast Recovery Rectifiers Pack of 5pcs
A fast recovery diode with a low forward voltage drop and a high surge current capability is the 1N4934 diode. Peak surge current of up to 30A and continuous current of 1A are the ratings for the 1N4934 rectifier. There is a 100V reverse voltage rating and a 200ns maximum reverse recovery time.A rectifier with fast recovery at 100V is the 1N4934. Applications that call for quick startup times and cool operating temperatures can employ these rectifiers. Excellent fast recovery capabilities and reverse-biased operation capability are features of these high-voltage, high-reliability diodes. High-voltage rectifiers can benefit from these diodes' low forward voltage drop, quick switching speed, and low resistance.
Features:-
- DC power supplies
- Inverters
- Converters
- Choppers
- Best Quality Product
