16mm Power Icon Push Button Switch | 220V Momentary Flat Head with Red Ring LED | IP67 Metal Body
Specification:-
- Model no. HBDS1-AGQ16F-11ETZ/J/N/220V/R
- LED Indicator: Red Ring LED – 220V
- Mounting holes: 16mm
- Action Type: Momentary (press-to-activate)
- Contact Type: 1NO (Normally Open)
- Material: Stainless steel body for durability
- Ingress Protection: IP65/IP67
- Terminals: Pin terminal
SKU: LA9606A
16mm Power Icon Push Button Switch | 220V Momentary Flat Head with Red Ring LED | IP67 Metal Body
This 16mm power icon push button switch with a power icon and red ring LED offers a sleek and practical solution for power control in electronic systems, machinery, and DIY projects. Designed with a flat head and momentary function, this switch activates only when pressed, making it ideal for start, reset, or input signal applications. The red LED ring illuminates clearly when powered, providing immediate visual feedback to users. It operates at 220V, suitable for high-voltage control systems, and integrates seamlessly into panels with a 16mm mounting hole. The nickel-plated brass construction offers superior durability, corrosion resistance, and a professional appearance. With an IP67 waterproof and dustproof rating, this switch performs reliably in demanding environments, including industrial, marine, and outdoor applications. The engraved power icon adds a clear indication of function, enhancing both usability and aesthetics. Installation is quick and secure with its pin terminal design, making it ideal for equipment upgrades or new builds. Whether you’re assembling a control panel or designing a custom interface, this push button switch delivers robust performance, safety, and style in a compact form.
Features:-
- High Durability
- Waterproof and dustproof
- Pin terminal for secure and simple wiring
- Low Voltage Operation Compatible
- Short actuation distance for fast, responsive switching
16mm power icon push button switch
Uncover Hidden Gems!
AI-Powered Suggestions
Frequently Asked Questions
We offer a wide range of switches including push button switches, toggle switches, momentary switches, self-lock switches, and smart WiFi switch modules. Options come in different sizes (12mm, 16mm, 19mm), colors (blue, green, yellow, white), and indicator lights for versatile applications.
Yes! Our collection includes Mini WiFi Smart Switch Modules that support app and voice control, making them perfect for smart home automation. Additionally, push button and toggle switches are widely used in DIY electronics, robotics, and educational projects.
Yes. Many of our switches come with built‑in LED indicators (blue, green, yellow, white) for Easy status monitoring. These are Especially useful in control panels, machinery, and DIY electronics projects where visibility matters.
We stock nickel‑plated brass push button switches (IP65 rated) and high‑current toggle switches that are suitable for industrial control panels, machinery, and automotive applications. For heavy loads, always check the voltage and current rating before installation.
Consider these factors :
- Type of operation (momentary vs self‑lock)
- Size & mounting hole (12mm, 16mm, 19mm)
- Current & voltage rating (AC 125V 3A, AC 250V 1.5A, etc.)
- Indicator requirement (LED or non‑LED)
- Application (DIY, home automation, industrial use)
Our filters and product Descriptions make it Easy to select the right switch.
. SPST (Single Pole Single Throw): Simple ON/OFF switch.
. SPDT (Single Pole Double Throw): One input, two outputs – used for selecting between two circuits.
DPDT (Double Pole Double Throw) : Controls two separate circuits simultaneously, often used in motor direction control
