300mAh 3.7V Li-ion Polymer Cell with BMS (602030)
Specification:-
- Rated Capacity: 300mAh
- Nominal Capacity: 300mAh
- Min. Capacity: 290mAh
- Cell Weight: 5.0≈ 6.0g
- Cell Initial Impedance: ≤110mΩ
- Normal Voltage: 3.7 V
- Limited Charging Voltage: 4.2 V
- Standard Charging Current: 60mA (0.2C)
- Cut-off Voltage: 3.0 V
SKU: HE8506A
300mAh 3.7V Li-ion Polymer Cell with BMS (602030)
The 300mAh 3.7V Li-ion Polymer Cell (602030) with Built-in BMS is a compact, high-performance rechargeable battery designed for small, portable devices. With a nominal capacity of 300mAh and a voltage of 3.7V, this battery offers reliable energy output and an extended lifespan, making it suitable for wearables, IoT gadgets, portable medical devices, and other low-power electronics. Its slim 602030 form factor (6mm x 20mm x 30mm) allows easy integration into compact designs without compromising performance. Equipped with a built-in Battery Management System (BMS), this cell ensures safe and efficient operation by providing protection against overcharging, over-discharging, and short circuits. The BMS not only enhances the battery's safety but also prolongs its operational life, making it a dependable choice for modern electronic applications. Additionally, the cell features a high energy density and low self-discharge rate, ensuring long-lasting performance even during extended storage.
Features:-
- High Capacity
- Long Cycle Life
- Low Self-Discharge
- Compact Design
- Fast Charging Support
- Wide Application Range
