Specification:
- Minimum Breakdown voltage: 133V
- Maximum Breakdown voltage: 148.0V
- Maximum Reverse Leakage Current: 10µa
- Maximum peak pulse current: 26A
- Maximum clamping voltage: 194.0V
- Power Dissipation: 5000W
- Package: R-6
SKU: HT8535E
5KP120A 10µA ,R-6 Transient Voltage Suppressor Pack of 5Pcs
The 5KP120A Series is designed to protect sensitive electronic equipment from voltage transients brought on by lightning strikes and other transient voltage events. a device that reduces the voltage drop it permits, thereby reducing the risk of electrical damage to a circuit. The TVS provides an electrical barrier that can protect your circuit from temporary effects despite its small size. This surface mount TVS device can be mounted on a circuit board. The device is ideal for protecting sensitive circuit elements. You can protect your electronics from high-voltage surges by using this equipment. It is made of strong, easily cleaned stainless steel and is intended to protect your devices from high-voltage surges.
Features:
- Very fast response time
- Glass passivated junction
- Excellent clamping capability
- Low incremental surge resistance
- High-temperature soldering
