Specification:-
- Package: PDIP14 (0.300", 7.62mm)
- Logic Function: NAND
- Number of Gates: 2 Gate
- Low Level Output Current: 6.8 mA
- High Level Output Current: - 6.8 mA
- Propagation Delay Time: 60 ns
- Supply Voltage - Min: 3 V
- Supply Voltage - Max: 18 V
SKU: ES8545A
CD4012BE NAND Gate IC 2-Channel Logic IC 14-PDIP
The CD4012BE is a dual 2-input NAND gate IC, Designed to perform logical NAND operations on two inputs. Each of the two channels in this IC has two inputs, and the output is the inverse of the logical AND of these inputs. This makes the CD4012BE an essential building block for various digital logic circuits, as NAND gates are universal gates and can be used to construct any other logic function, such as AND, OR, and NOT. This IC is part of the CD4000 series, which is known for its compatibility with both CMOS and TTL logic systems. The CD4012BE operates within a wide voltage range of 3V to 15V, making it versatile for different voltage logic systems. It is housed in a 14-pin PDIP (Plastic Dual In-line Package), suitable for through-hole mounting in PCB designs. The CD4012BE is commonly used in logic circuits, memory elements, and combinational or sequential digital designs. Its wide operating voltage range and reliability in low-power systems make it ideal for use in various electronic applications, including signal processing, Digital control systems, and interfacing tasks.
Features :-
- Dual 2-input NAND gate
- 14-pin PDIP for through-hole mounting
- Suitable for energy-efficient designs
- Two independent 2-input NAND gates in a single package
