CD4019BE AND/OR Gate Configurable 4 Circuit 2, 2 Input Logic IC 16-PDIP
Specification:-
- Package: PDIP16 (0.300", 7.62mm)
- Number of Circuits: 4
- Number of Inputs: 2
- Supply Voltage-Max (Vsup): 18 V
- Supply Voltage-Min (Vsup): 3 V
- Supply Voltage-Nom (Vsup): 5 V
- Operating Temperature: -55°C ~ 125°C
SKU: XA8539A
CD4019BE AND/OR Gate Configurable 4 Circuit 2, 2 Input Logic IC 16-PDIP
The CD4019BE is a highly flexible AND/OR gate logic IC that features a configurable 4-circuit design, allowing for versatile logic operations in digital circuits. With two inputs per gate, this IC provides the ability to perform both AND and OR logical functions, depending on how it is configured, making it ideal for use in a wide range of digital logic applications. The IC is housed in a 16-pin PDIP (Plastic Dual In-line Package), which facilitates easy integration into standard through-hole PCB designs. The CD4019BE operates with a wide supply voltage range of 3V to 18V, offering flexibility for use in both low and high-voltage logic circuits. It is designed to deliver reliable and noise-resistant performance in a variety of environments. The IC features low power consumption and high noise immunity, ensuring stable operation even in demanding conditions. Due to its configurable nature, the CD4019BE is particularly suitable for systems that require custom logic designs, including state machines, signal processing, and control systems.
Features:-
- 2-input logic gates for each circuit
- 16-pin PDIP for easy through-hole integration
- 4 circuits, each configurable as an AND or OR gate
- Suitable for energy-efficient designs
