Specification:-
- Package: SOIC16 (0.154", 3.90mm)
- Number of Input Lines: 2 Input
- Number of Output Lines: 1 Output
- Propagation Delay Time: 14.1 ns
- Supply Voltage - Min: 4.5 V
- Supply Voltage - Max: 5.5 V
SKU: OM8546A
CD74ACT151M96 Multiplexer 1 x 8:1 Logic IC 16-SOIC
The CD74ACT151M96 is an 8-channel multiplexer IC that allows one of eight data inputs to be routed to a single output, based on a 3-bit binary selection signal. This multiplexer is part of the ACT (Advanced CMOS with TTL compatibility) family, which ensures high-speed performance, low power consumption, and compatibility with both TTL and CMOS logic systems. The 1 x 8:1 configuration means that the IC has one output and eight inputs, enabling efficient signal routing in digital systems. The CD74ACT151M96 features active-low enable (G) inputs, which allow for the control of the output based on external signals, ensuring it can be integrated seamlessly into larger logic systems. It operates within a supply voltage range of 4.5V to 5.5V and is housed in a 16-pin SOIC (Small Outline Integrated Circuit) package, making it ideal for compact, surface-mount designs. This IC is commonly used in applications such as data multiplexing, memory addressing, and signal routing.
Features :-
- 1 output and 8 selectable input channels
- Active-low enable input for output control
- Compatible with TTL logic families
- Fast switching for high-frequency applications
