DM74LS33M NOR Gate Logic IC 4 Channel Open Collector 14-SOIC

Specification:-

  • Package: SOIC14 (0.154", 3.90mm)
  • Number of Output Lines: 1 Output
  • Low Level Output Current: 24 mA
  • High Level Output Current: - 100 uA
  • Propagation Delay Time: 22 ns
  • Supply Voltage - Min: 4.75 V
  • Supply Voltage - Max: 5.25 V
Available in Pack Of:

SKU: GV8517A

MRP Rs. 680.00
Rs. 500.00 (Incl. Tax)
Rs. 423.73 (+18% GST extra)
Rs. 423.73 / pack of 1 = Rs. 423.73 per piece
Buy to Get ₹0 off!
₹0 Special Discount Applied

DM74LS33M NOR Gate Logic IC 4 Channel Open Collector 14-SOIC

The DM74LS33M is a 4-channel NOR Gate Logic IC designed with open-collector outputs, providing flexibility in wired-logic configurations and external pull-up resistor usage. Each gate features two inputs, and its open-collector design suits it particularly for applications requiring signal level shifting or multiple-output connections. This IC is housed in a compact 14-SOIC (Small Outline Integrated Circuit) package, ideal for surface-mount applications in modern PCB designs. It operates on a standard TTL voltage range of 4.75V to 5.25V, ensuring compatibility with other TTL-based logic components. The open-collector output configuration allows the IC to sink currents, enabling wired-AND logic or driving external loads such as LEDs or relays. The DM74LS33M is designed for reliable performance with low power dissipation while maintaining high noise immunity. Its operational speed and open-collector output capability make it well-suited for applications in timing, data communication, and digital system interfacing. Additionally, the IC is optimized for stability across a wide temperature range, making it suitable for industrial and commercial environments.

Feature:-

  • Low On-Resistance
  • High Voltage Rating
  • High Current Capability
