DS1232LPS Supervisor Open Drain, Push-Pull 1 Channel 16-SOIC
Specification:-
- Package: SOIC16 (0.295", 7.50mm)
- Mounting Style: SMD/SMT
- Number of Pins: 16 Pin
- Supply Current-Max (Isup): 0.5 mA
- Supply Voltage-Max (Vsup): 5.5 V
- Supply Voltage-Min (Vsup): 4.5 V
- Supply Voltage-Nom (Vsup): 5 V
SKU: DP8470A
DS1232LPS Supervisor Open Drain, Push-Pull 1 Channel 16-SOIC
The DS1232LPS Supervisor IC is a versatile and robust system monitor designed to enhance the reliability of electronic systems by supervising power supply levels and providing reset signals during voltage anomalies or microprocessor malfunctions. Packaged in a compact 16-pin SOIC (Small Outline Integrated Circuit), it supports a single channel for efficient power supervision. The IC features both open-drain and push-pull output configurations, offering flexibility in interfacing with various systems. It monitors the supply voltage and ensures that the system is held in a reset state during power-up, power-down, or if the voltage drops below a predefined threshold. This functionality prevents erratic operation and data corruption during power fluctuations. Additionally, the DS1232LPS includes a watchdog timer to monitor microprocessor activity. If the system fails to toggle the watchdog input within a specified time, the IC generates a reset signal, ensuring continuous and stable operation.
Features:-
- High-Speed Performance
- Low Power Consumption
- Wide Operating Voltage Range
