HFD3/24-L1SR(131) Surface Mount 8-Pin 24V 2A DPDT Signal Latching Relay
Specification:-
- Package: SMD 8-PIN
- Rated coil voltage: 12V DC
- Contact current max: 2A
- AC contacts rating: 0.5A / 125V AC
- DC contacts rating: 2A / 30V DC
- Switched voltage: max. 220V DC, max. 250V AC
- Contacts configuration: DPDT
- Coil power consumption: 140mW
- Operating temperature: -40°C to 85°C
SKU: RE8536A
HFD3/24-L1SR(131) Surface Mount 8-Pin 24V 2A DPDT Signal Latching Relay
The HFD3/24-L1SR(131) is a high-performance surface-mount DPDT (Double Pole Double Throw) signal latching relay designed for precise switching and low-power applications. Operating at a nominal voltage of 24V and capable of handling up to 2A, this relay is ideal for signal control, telecommunications, and low-power switching circuits. Its 8-pin surface-mount design enables compact installation on modern, space-constrained printed circuit boards (PCBs), making it suitable for use in miniaturized electronic devices and compact systems. This latching relay features the ability to maintain its state without continuous power supply, making it energy-efficient for systems that require infrequent switching. The HFD3/24-L1SR(131) provides reliable and safe operation with high dielectric strength, ensuring proper insulation between the coil and contacts. It is engineered for durability and high switching reliability, capable of withstanding frequent switching cycles while minimizing power consumption.
Features:-
- Low Power Consumption
- Compact and easy to mount on PCBs
- Low Power Consumption
- Provides safe insulation between the coil and contacts.
- Designed for long-term use with frequent switching cycles.
