Specification:-
- Package: SMD 8-PIN
- Rated coil voltage: 12V DC
- Contact current max: 2A
- AC contacts rating: 0.5A / 125V AC
- DC contacts rating: 2A / 30V DC
- Switched voltage: max. 220V DC, max. 250V AC
- Contacts configuration: DPDT
- Coil power consumption: 140mW
- Operating temperature: -40°C to 85°C
SKU: RA8536A
HFD3/24-S1R Surface Mount 8-Pin 24V 2A DPDT Signal Relay
The HFD3/24-S1R is a high-performance, surface-mount DPDT (Double Pole Double Throw) signal relay designed for precise and efficient switching in low-power circuits. With a nominal voltage rating of 24V and capable of handling up to 2A, this relay is ideal for use in signal processing applications, telecommunications, control systems, and low-power switching tasks. Its compact 8-pin surface-mount design allows for easy integration into modern, space-constrained circuit boards, making it an excellent choice for miniaturized electronic devices. The HFD3/24-S1R relay features high dielectric strength, providing reliable insulation between the coil and contacts, ensuring safe operation even in sensitive environments. Designed for long operational life and high switching reliability, this relay is engineered to handle frequent switching cycles without compromising performance. Its low power consumption ensures energy-efficient operation, making it an optimal choice for systems requiring minimal power draw.
Features:-
- Low Power Consumption
- Compact and easy to mount on PCBs
- Low Power Consumption
- Provides safe insulation between the coil and contacts.
- Designed for long-term use with frequent switching cycles.
