HFE7/12-2HS-L1 Through Hole 6-Pin 12V 8A SPST Subminiature Intermediate High Power Relay
Specification:-
- Package: DIP 6-Pin
- Control Voltage: 12V DC
- Load Current Capacity: Up to 8A
- Contact arrangement: 2 Form A
- Ambient Temperature: -40°C ~ 105°C
- Configuration: SPST (Single Pole Single Throw)
SKU: QO8536A
HFE7/12-2HS-L1 Through Hole 6-Pin 12V 8A SPST Subminiature Intermediate High Power Relay
The HFE7/12-2HS-L1(317) is a subminiature intermediate power relay with a single-coil latching mechanism, designed for reliable and efficient switching in space-constrained applications. This relay features a 12V DC coil voltage and a maximum load capacity of 8A, making it suitable for low-to-medium power applications. With a 2 Form A (DPST-NO) contact configuration and a 6-pin through-hole design, it provides a secure and stable PCB mounting solution while enabling precise control of electrical circuits. This single-coil latching relay retains its contact position even after the removal of power, making it energy-efficient and ideal for applications where power conservation is critical. Its robust design ensures excellent electrical insulation, low contact resistance, and a long operational life, making it suitable for a wide range of industrial, commercial, and consumer applications.
Features:-
- 6-Pin Through-Hole Design
- Positive Polarity Design
- Durable and Long-Lasting
- Low Power Consumption
- High Inrush Current Capability
