IL317L 1-Output 100mA Linear Voltage Regulator IC Positive Adjustable TO-92
Specification:-
- Package: TO-92-3
- Input - Output Voltage Differential: 40V
- Reference Voltage : 1.2~1.3V
- Load Regulation: 6.0 mV
- Operating Junction Temperature Range: -40°C to +125°C
SKU: AA8410A
IL317L 1-Output 100mA Linear Voltage Regulator IC Positive Adjustable TO-92
The IL317L is a compact, positive adjustable linear voltage regulator IC designed to provide a stable output voltage for low-current applications. With a maximum output current of 100mA, it is an ideal solution for powering small circuits, sensors, and battery-powered devices. The output voltage can be adjusted from 1.25V to 37V using an external resistor divider, making it highly versatile for different voltage requirements. Packaged in a TO-92 form factor, the IL317L is small, efficient, and easy to integrate into space-constrained designs. The IC features low dropout voltage, ensuring efficient regulation even with small input-to-output voltage differences. Built-in protection features, such as thermal shutdown and current limiting, help to safeguard the IC and connected components under overload or short-circuit conditions.
Features:-
- TO-92, compact and easy to integrate.
- Thermal Shutdown Protection
- Protects against excessive current draw and short circuits.
- Ensures efficient operation with minimal input-output voltage differential.
