ILD5X009T 5300Vrms 2-Channel Optoisolator Transistor Output 8-SMD Gull Wing
Specification:-
- Package: SMD8 Gull Wing
- Number of Channels: 2
- Voltage - Isolation: 5300Vrms
- Voltage - Output (Max): 70V
- Current - Output / Channel: 50mA
- Voltage - Forward (Vf) (Typ): 1.25V
- Current - DC Forward (If) (Max): 60 mA
- Vce Saturation (Max): 400mV
- Operating Temperature: -40°C ~ 100°C
SKU: AY8410A
ILD5X009T 5300Vrms 2-Channel Optoisolator Transistor Output 8-SMD Gull Wing
The ILD5X009T is a high-reliability, 2-channel optoisolator designed to provide electrical isolation and signal coupling between input and output circuits. It features a transistor output and delivers an isolation voltage of up to 5300Vrms, making it ideal for industrial and safety-critical applications. The device is housed in an 8-SMD Gull Wing package, which is compact and suitable for surface-mount technology (SMT) assembly, ensuring ease of integration into modern PCB designs. The ILD5X009T employs two infrared LEDs optically coupled to phototransistors, allowing the transmission of electrical signals while maintaining galvanic isolation. With its dual-channel configuration, it provides versatile solutions for isolating multiple signal paths in high-voltage environments.
Applications:-
- Industrial control systems.
- Motor drive circuits.
- Data communications in high-voltage systems.
- Power supply feedback and monitoring.
- Isolation in microcontroller and logic interfaces.
