SMD DIODE
MURS160T3G 600V 2A Surface mount glass passivated Ultrafast SMD diode pack of 50pcs
Specification
- Max. repetitive reverse voltage: 600V
- Forward current: 2A
- Max. forward recovery time: 50ns
- Max. peak forward surge current: 35A
- Max. DC reverse current: 5µA
SKU: 18759HB
MRP Rs. 320.85
Rs.
279.00
(Incl. Tax)
Rs.
236.44
(+18% GST extra)
Buy to Get ₹0 off!
₹0 Special Discount Applied
MURS160T3G 600V 2A Surface mount glass passivated Ultrafast SMD diode pack of 50pcs
This is a surface mount superfast SMD diode. This device features a glass passivated junction, a low profile package, and a fast recovery time for high efficiency. It is an electronic component that allows the current to flow in only one direction. It is a two-terminal semiconductor device. This diode can pass currents up to 2A. This diode conducts current when it is forward bias and blocks the flow of current when reverse biased. It is ideally suited for high voltage, high-frequency rectification, or freewheeling. And also protection in surface mount applications where compact size and weight are critical to the system.
Package includes
This is the pack of 50 pieces of MURS160T3G 600V 2A Surface mount glass passivated Ultrafast SMD diode
Features
- High current capability
- Ultra-fast response
- Low forward voltage drop
- High surge current capability
