HIGH EFFICIENCY RECTIFIERS

R-6, HER604 300V High Efficiency Rectifiers Diode pack of 5pcs

Specification

1. Maximum respective peak reverse voltage : 300v
2. Maximum average rectified current : 6.0A
3. Maxim reverse current : 10µA
4. Case :  R-6
5. Non-Repetitive Peak Forward Surge Current : 250A
6. Maxim forward voltage : 1.3V
7. Maximum reverse recovery time : 50ns

HER152 100V,DO-15 High Efficiency Rectifiers Pack of 5pcs

Specification:-

• Maximum repetitive peak reverse voltage : 100V
• Peak forward surge current 8.3ms single half sine- wave : 50A
• Maximum reverse current @ VRRM TA = 25°C : 5.0µA
• Maximum reverse recovery time : 50ns
• Package : DO-15

HER106 600V ,DO-41 High Efficiency Rectifiers Pack of 5pcs

Specification:-

• Maximum repetitive peak reverse voltage : 600V
• Peak forward surge current 8.3ms single half sine- wave : 30A
• Maximum reverse current @ VRRM TA = 25°C : 5.0µA
• Maximum reverse recovery time : 70ns
• Package : DO-41

HER108 1000V ,DO-41 High Efficiency Rectifiers Pack of 5pcs

Specification:-

• Maximum repetitive peak reverse voltage : 1000V
• Peak forward surge current 8.3ms single half sine- wave : 30A
• Maximum reverse current @ VRRM TA = 25°C : 5.0µA
• Maximum reverse recovery time : 70ns
• Package : DO-41

DO-41, UF4004 400V High Efficiency Rectifiers Diode pack of 5pcs

Specification

1. Maximum respective peak reverse voltage : 400v
2. Maximum average rectified current : 1.0A
3. Maxim reverse current : 5.0µA
4. Case :  DO-41
5. Non-Repetitive Peak Forward Surge Current : 30A
6. Maxim forward voltage : 1.0V
7. Maximum reverse recovery time : 50ns

HER102S 100V ,A-405 High Efficiency Rectifiers Pack of 5pcs

Specification:-

• Maximum repetitive peak reverse voltage : 100V
• Peak forward surge current 8.3ms single half sine- wave : 30A
• Maximum reverse current @ VRRM TA = 25°C : 5.0µA
• Maximum reverse recovery time : 50ns
• Package : A-405

R-6, HER603 200V High Efficiency Rectifiers Diode pack of 5pcs

Specification

1. Maximum respective peak reverse voltage : 200v
2. Maximum average rectified current : 6.0A
3. Maxim reverse current : 10µA
4. Case :  R-6
5. Non-Repetitive Peak Forward Surge Current : 250A
6. Maxim forward voltage : 1.0V
7. Maximum reverse recovery time : 50ns

HER104S 300V ,A-405 High Efficiency Rectifiers Pack of 5pcs

Specification:-

• Maximum repetitive peak reverse voltage : 300V
• Peak forward surge current 8.3ms single half sine- wave : 30A
• Maximum reverse current @ VRRM TA = 25°C : 5.0µA
• Maximum reverse recovery time : 50ns
• Package : A-405

DO-201AD, UF5401 100V High Efficiency Rectifiers Diode pack of 5pcs

Specification

1. Maximum respective peak reverse voltage : 100v
2. Maximum average rectified current : 3.0A
3. Maxim reverse current : 5.0µA
4. Case :  DO-201AD
5. Non-Repetitive Peak Forward Surge Current : 150A
6. Maxim forward voltage : 1.0V
7. Maximum reverse recovery time : 50ns

HER103S 200V ,A-405 High Efficiency Rectifiers Pack of 5pcs

Specification:-

• Maximum repetitive peak reverse voltage : 200V
• Peak forward surge current 8.3ms single half sine- wave : 30A
• Maximum reverse current @ VRRM TA = 25°C : 5.0µA
• Maximum reverse recovery time : 50ns
• Package : A-405

HER104 300V ,DO-41 High Efficiency Rectifiers Pack of 5pcs

Specification:-

• Maximum repetitive peak reverse voltage : 300V
• Peak forward surge current 8.3ms single half sine- wave : 30A
• Maximum reverse current @ VRRM TA = 25°C : 5.0µA
• Maximum reverse recovery time : 50ns
• Package : DO-41

HER105 400V ,DO-41 High Efficiency Rectifiers Pack of 5pcs

Specification:-

• Maximum repetitive peak reverse voltage : 400V
• Peak forward surge current 8.3ms single half sine- wave : 30A
• Maximum reverse current @ VRRM TA = 25°C : 5.0µA
• Maximum reverse recovery time : 50ns
• Package : DO-41
