HIGH EFFICIENCY RECTIFIERS

DO-201AD, HER305 400V High Efficiency Rectifiers Diode pack of 5pcs

Specification

1. Maximum respective peak reverse voltage : 400v
2. Maximum average rectified current : 3.0A
3. Maxim reverse current : 5.0µA
4. Case :  DO-201AD
5. Non-Repetitive Peak Forward Surge Current : 200A
6. Maxim forward voltage : 1.3V
7. Maximum reverse recovery time : 50ns

R-6, HER601 50V High Efficiency Rectifiers Diode pack of 5pcs

Specification

1. Maximum respective peak reverse voltage : 50v
2. Maximum average rectified current : 6.0A
3. Maxim reverse current : 10µA
4. Case :  R-6
5. Non-Repetitive Peak Forward Surge Current : 250A
6. Maxim forward voltage : 1.0V
7. Maximum reverse recovery time : 50ns

DO-201AD, HER308 1000V High Efficiency Rectifiers Diode pack of 5pcs

Specification

1. Maximum respective peak reverse voltage : 1000v
2. Maximum average rectified current : 3.0A
3. Maxim reverse current : 5.0µA
4. Case :  DO-201AD
5. Non-Repetitive Peak Forward Surge Current : 150A
6. Maxim forward voltage : 1.7V
7. Maximum reverse recovery time : 70ns

R-6, HER607 800V High Efficiency Rectifiers Diode pack of 5pcs

Specification

1. Maximum respective peak reverse voltage : 800v
2. Maximum average rectified current : 6.0A
3. Maxim reverse current : 10µA
4. Case :  R-6
5. Non-Repetitive Peak Forward Surge Current : 250A
6. Maxim forward voltage : 1.7V
7. Maximum reverse recovery time : 70ns

DO-201AD, UF5407 800V High Efficiency Rectifiers Diode pack of 5pcs

Specification

1. Maximum respective peak reverse voltage : 800v
2. Maximum average rectified current : 3.0A
3. Maxim reverse current : 5.0µA
4. Case :  DO-201AD
5. Non-Repetitive Peak Forward Surge Current : 150A
6. Maxim forward voltage : 1.7V
7. Maximum reverse recovery time : 75ns

1H2 100V ,R-1 High Efficiency Rectifiers Pack of 5pcs

Specification:-

• Maximum repetitive peak reverse voltage : 100V
• Peak forward surge current 8.3ms single half sine- wave : 25A
• Maximum reverse current @ VRRM TA = 25°C : 5.0µA
• Maximum reverse recovery time : 50ns
• Package : R-1

HER201 50V,DO-15 High Efficiency Rectifiers Pack of 5pcs

Specification:-

• Maximum repetitive peak reverse voltage : 50V
• Peak forward surge current 8.3ms single half sine- wave : 60A
• Maximum reverse current @ VRRM TA = 25°C : 5.0µA
• Maximum reverse recovery time : 50ns
• Package : DO-15

DO-201AD, UF5404 400V High Efficiency Rectifiers Diode pack of 5pcs

Specification

1. Maximum respective peak reverse voltage : 400v
2. Maximum average rectified current : 3.0A
3. Maxim reverse current : 5.0µA
4. Case :  DO-201AD
5. Non-Repetitive Peak Forward Surge Current : 150A
6. Maxim forward voltage : 1.0V
7. Maximum reverse recovery time : 50ns

1H3 200V ,R-1 High Efficiency Rectifiers Pack of 5pcs

Specification:-

• Maximum repetitive peak reverse voltage : 200V
• Peak forward surge current 8.3ms single half sine- wave : 25A
• Maximum reverse current @ VRRM TA = 25°C : 5.0µA
• Maximum reverse recovery time : 50ns
• Package : R-1

1H4 300V ,R-1 High Efficiency Rectifiers Pack of 5pcs

Specification:-

• Maximum repetitive peak reverse voltage : 300V
• Peak forward surge current 8.3ms single half sine- wave : 25A
• Maximum reverse current @ VRRM TA = 25°C : 5.0µA
• Maximum reverse recovery time : 50ns
• Package : R-1

HER158 1000V,DO-15 High Efficiency Rectifiers Pack of 5pcs

Specification:-

• Maximum repetitive peak reverse voltage : 1000V
• Peak forward surge current 8.3ms single half sine- wave : 50A
• Maximum reverse current @ VRRM TA = 25°C : 5.0µA
• Maximum reverse recovery time : 70ns
• Package : DO-15

R-6, HER604 300V High Efficiency Rectifiers Diode pack of 5pcs

Specification

1. Maximum respective peak reverse voltage : 300v
2. Maximum average rectified current : 6.0A
3. Maxim reverse current : 10µA
4. Case :  R-6
5. Non-Repetitive Peak Forward Surge Current : 250A
6. Maxim forward voltage : 1.3V
7. Maximum reverse recovery time : 50ns
