DIODE & ZENER

MM3ZB27 300mW ,SOD-323 Packaging Diodes Pack of 5pcs

Specification:

• Power Dissipation : 300mW
• Nominal Zener Voltage : 27V
• Minimum Zener voltage : 26.46V
• Maximum Zener voltage : 27.54V
• Maximum Reverse Current : 0.1µa
• Package : SOD-323

1N5406G 600V ,DO-21AD Glass Passivated General Purpose Rectifiers Pack of 5pcs

Specification:-

• Maximum repetitive peak reverse voltage : 600V
• Maximum average rectified current : 3.0A
• Peak forward surge current 8.3ms single half sine- wave : 200A
• Maximum reverse current @ VRRM TA = 25°C : 5.0µA
• Package : DO-21AD

US2A 50V ,Surface Mount High Efficiency Rectifiers Pack of 5pcs

Specification:-

1. Package : SMA/SMB
2. Maximum respective peak reverse voltage : 50v
3. Maximum average rectified current : 2.0A
4. Forward peak surge current@8.3ms single half sine-wave : 50A
5. Maximum reverse current : 5.0µa
6. Maximum reverse recovery time : 50ns

SMBJ20A 600W Surface Mount Transient Voltage Suppressors Pack of 5pcs

Specification:-

1. Package : SMB/SMB(G)
2. Minimum Breakdown voltage : 22.2V
3. Maximum Breakdown voltage : 24.5V
4. Stand-off voltage : 20.0
5. Maximum reverse leakage current : 5.0
6. Maximum peak pulse current : 18.5A
7. Maximum clamping voltage : 32.4V
8. Power dissipation : 600W

5KP110A 10µA ,R-6 Transient Voltage Suppressor Pack of 5Pcs

Specification:

• Minimum Breakdown voltage: 122V
• Maximum Breakdown voltage: 135.0V
• Maximum Reverse Leakage Current: 10µa
• Maximum peak pulse current: 28A
• Maximum clamping voltage: 177.0V
• Power Dissipation: 5000W
• Package: R-6

5KP5.0 5000µA ,R-6 Transient Voltage Suppressor Pack of 5Pcs

Specification:

• Minimum Breakdown voltage: 6.40V
• Maximum Breakdown voltage: 7.30V
• Maximum Reverse Leakage Current: 5000µa
• Maximum peak pulse current: 520A
• Maximum clamping voltage: 9.6V
• Power Dissipation: 5000W
• Package: R-6

1.5KE150 5.0µA, DO-201AD Transient Voltage Suppressor Pack of 5Pcs

Specification:

• Minimum Breakdown voltage: 135.0V
• Maximum Breakdown voltage: 165.0V
• Maximum Reverse Leakage Current: 5.0µa
• Maximum peak pulse current: 7.0A
• Maximum clamping voltage: 215.0V
• Maximum Temperature Coefficient of VBR: 0.108%
• Power Dissipation: 1500W
• Package: DO-201AD

P6KE220A 5.0µA, DO-15 Transient Voltage Suppressor Pack of 5Pcs

Specification:

• Minimum Breakdown voltage: 209.0V
• Maximum Breakdown voltage: 231.0V
• Maximum Reverse Leakage Current: 5.0µa
• Maximum peak pulse current: 1.83A
• Maximum clamping voltage: 328.0V
• Maximum Temperature Coefficient of VBR: 0.108%
• Power Dissipation: 600W
• Package: DO-15

KBPC25-W, MB252W 25A 200V Bridge Rectifiers Diode pack of 2pcs

Specification

1. Case : KBPC25-W
2. Maximum respective peak reverse voltage : 200v
3. Maximum average rectified current : 25.0A
4. Maxim reverse current : 10.0µA
5. Non-Repetitive Peak Forward Surge Current : 300A
6. Maxim forward voltage : 1.1V

1.5KE8.2 200µA, DO-201AD Transient Voltage Suppressor Pack of 5Pcs

Specification:

1. Minimum Breakdown voltage: 7.38V
2. Maximum Breakdown voltage: 9.02V
3. Maximum Reverse Leakage Current: 200µa
4. Maximum peak pulse current: 120A
5. Maximum clamping voltage: 12.5V
6. Maximum Temperature Coefficient of VBR: 0.065%
7. Power Dissipation: 1500W
8. Package: DO-201AD

1.5KE150A 5.0µA, DO-201AD Transient Voltage Suppressor Pack of 5Pcs

Specification:

• Minimum Breakdown voltage: 143.0V
• Maximum Breakdown voltage: 158.0V
• Maximum Reverse Leakage Current: 5.0µa
• Maximum peak pulse current: 7.2A
• Maximum clamping voltage: 207.0V
• Maximum Temperature Coefficient of VBR: 0.108%
• Power Dissipation: 1500W
• Package: DO-201AD

1.5KE13A 5.0µA, DO-201AD Transient Voltage Suppressor Pack of 5Pcs

Specification:

1. Minimum Breakdown voltage: 12.4V
2. Maximum Breakdown voltage: 13.7V
3. Maximum Reverse Leakage Current: 5.0µa
4. Maximum peak pulse current: 82.0A
5. Maximum clamping voltage: 18.2V
6. Maximum Temperature Coefficient of VBR: 0.081%
7. Power Dissipation: 1500W
8. Package: DO-201AD
