DIODE & ZENER

SMA(G), GS1K 800V Surface Mount General Purpose Rectifiers Diode pack of 5pcs

Specification

1. Case : SMA(G)
2. Maximum respective peak reverse voltage : 800v
3. Maximum average rectified current : 1.0A
4. Maxim reverse current : 5.0µA
5. Non-Repetitive Peak Forward Surge Current : 30A
6. Maxim forward voltage : 1.1V

UF1G 400V ,Surface Mount High Efficiency Rectifiers Pack of 5pcs

Specification:-

1. Package : SMA(G)
2. Maximum respective peak reverse voltage : 400v
3. Maximum average rectified current : 1.0A
4. Forward peak surge current@8.3ms single half sine-wave : 30A
5. Maximum reverse current : 5.0µA
6. Maximum reverse recovery time : 50ns

SMA, SMAJ30A, 30.0V Surface Mount Transient Voltage Suppressors Rectifiers Diode pack of 5pcs

Specification

1. Case : SMA
2. Maximum respective peak reverse voltage : 30.0v
3. Maximum average rectified current : 6.2A
4. Maxim reverse current : 5.0µA
5. Maxim forward voltage : 48.4V

5KP7.0A 1000µA ,R-6 Transient Voltage Suppressor Pack of 100

pecification:

• Minimum Breakdown voltage: 7.78V
• Maximum Breakdown voltage: 8.60V
• Maximum Reverse Leakage Current: 1000µa
• Maximum peak pulse current: 417A
• Maximum clamping voltage: 12.0V
• Power Dissipation: 5000W
• Package: R-6

SMC(G) SMCJ10A 1500W Surface Mount Transient Voltage Suppressors Pack of 5pcs

Specification

1. Case : SMC(G)
2. Stand-off voltage : 10.0V
3. Maximum peak pulse current : 88.2A
4. Maxim reverse current : 5.0µA
5. Maximum clamping voltage : 17.0V
6. Power dissipation : 1500W

WOB, RB151 1.5A 50V Bridge Rectifiers Diode pack of 5pcs

Specification

1. Case : WOB
2. Maximum respective peak reverse voltage : 50v
3. Maximum average rectified current : 1.5A
4. Maxim reverse current : 5.0µA
5. Non-Repetitive Peak Forward Surge Current : 50A
6. Maxim forward voltage : 1.0V

1.5KE18 5.0µA, DO-201AD Transient Voltage Suppressor Pack of 100

Specification:

• Minimum Breakdown voltage: 16.2V
• Maximum Breakdown voltage: 19.8V
• Maximum Reverse Leakage Current: 5.0µa
• Maximum peak pulse current: 56.5A
• Maximum clamping voltage: 26.5V
• Maximum Temperature Coefficient of VBR: 0.088%
• Power Dissipation: 1500W
• Package: DO-201AD

1.5KE15A 5.0µA, DO-201AD Transient Voltage Suppressor Pack of 100

Specification:

• Minimum Breakdown voltage: 14.3V
• Maximum Breakdown voltage: 15.8V
• Maximum Reverse Leakage Current: 5.0µa
• Maximum peak pulse current: 71.0A
• Maximum clamping voltage: 21.2V
• Maximum Temperature Coefficient of VBR: 0.084%
• Power Dissipation: 1500W
• Package: DO-201AD

P6KE220A 5.0µA, DO-15 Transient Voltage Suppressor Pack of 100

Specification:

• Minimum Breakdown voltage: 209.0V
• Maximum Breakdown voltage: 231.0V
• Maximum Reverse Leakage Current: 5.0µa
• Maximum peak pulse current: 1.83A
• Maximum clamping voltage: 328.0V
• Maximum Temperature Coefficient of VBR: 0.108%
• Power Dissipation: 600W
• Package: DO-15

SA12 1.0µA ,DO-15 Transient Voltage Suppressors Pack of 100

Specification:-

• Breakover voltage : Min(V) 13.3 , Max(V) 16.3
• Maximum peak current : 22.7A
• Maximum reverse leakage current @ VRWM : 1.0µA
• Power dissipation :500W
• Package : DO-15

DO-41, 1N4935G 200V Glass Passivated Fast Recovery Rectifiers Diode pack of 5pcs

Specification

1. Case : DO-41
2. Maximum respective peak reverse voltage : 200v
3. Maximum average rectified current : 1.0A
4. Maxim reverse current : 5.0µA
5. Non-Repetitive Peak Forward Surge Current : 30A
6. Maxim forward voltage : 1.3V
7. Maximum reverse recovery time : 200ns

FR2A 50V ,Surface Mount Fast Recovery Rectifiers Pack of 5pcs

Specification:-

1. Package : SMB(G)
2. Maximum respective peak reverse voltage : 50v
3. Maximum average rectified current : 2.0A
4. Forward peak surge current@8.3ms single half sine-wave : 50A
5. Maximum reverse current : 5.0µa
6. Maximum reverse recovery time : 150ns
