DIODE & ZENER

DO-41, FR103G 200V Glass Passivated Fast Recovery Rectifiers Diode pack of 5pcs

Specification

1. Case : DO-41
2. Maximum respective peak reverse voltage : 200v
3. Maximum average rectified current : 1.0A
4. Maxim reverse current : 5.0µA
5. Non-Repetitive Peak Forward Surge Current : 30A
6. Maxim forward voltage : 1.3V
7. Maximum reverse recovery time : 150ns

RL204G 400V, DO-15 Glass Passivated General Purpose Rectifiers Pack of 5pcs

Specification:-

• Maximum repetitive peak reverse voltage : 400V
• Maximum average rectified current : 2.0A
• Peak forward surge current 8.3ms single half sine- wave : 70A
• Maximum reverse current @ VRRM TA = 25°C : 5.0µA
• Package : DO-15

DO-41, SF13 150V Super Fast Rectifiers Diode pack of 5pcs

Specification

1. Maximum respective peak reverse voltage : 150v
2. Maximum average rectified current : 1.0A
3. Maxim reverse current : 5.0µA
4. Case :  DO-41
5. Non-Repetitive Peak Forward Surge Current : 30A
6. Maxim forward voltage : 0.95V
7. Maximum reverse recovery time : 35ns

SMBJ15 600W Surface Mount Transient Voltage Suppressors Pack of 5pcs

Specification:-

1. Package : SMB/SMB(G)
2. Minimum Breakdown voltage : 16.7V
3. Maximum Breakdown voltage : 20.4V
4. Stand-off voltage : 15.0
5. Maximum reverse leakage current : 5.0
6. Maximum peak pulse current : 22.3A
7. Maximum clamping voltage : 26.9V
8. Power dissipation : 600W

KBPC25-W, MB256W 25A 600V Bridge Rectifiers Diode pack of 2pcs

Specification

1. Case : KBPC25-W
2. Maximum respective peak reverse voltage : 600v
3. Maximum average rectified current : 25.0A
4. Maxim reverse current : 10.0µA
5. Non-Repetitive Peak Forward Surge Current : 300A
6. Maxim forward voltage : 1.1V

1.5KE12 5.0µA, DO-201AD Transient Voltage Suppressor Pack of 5Pcs

Specification:

1. Minimum Breakdown voltage: 10.8V
2. Maximum Breakdown voltage: 13.2V
3. Maximum Reverse Leakage Current: 5.0µa
4. Maximum peak pulse current: 87.0A
5. Maximum clamping voltage: 17.3V
6. Maximum Temperature Coefficient of VBR: 0.078%
7. Power Dissipation: 1500W
8. Package: DO-201AD

SA6.0A 600µA ,DO-15 Transient Voltage Suppressors Pack of 5pcs

Specification:-

• Breakover voltage : Min(V) 6.67 , Max(V) 7.37
• Maximum peak current : 48.5A
• Maximum reverse leakage current @ VRWM : 600µA
• Power dissipation :500W
• Package : DO-15

SA5.0 600µA ,DO-15 Transient Voltage Suppressors Pack of 5pcs

Specification:-

• Breakover voltage : Min(V) 6.40 , Max(V) 7.30
• Maximum peak current : 52.0A
• Maximum reverse leakage current @ VRWM : 600µA
• Power dissipation :500W
• Package : DO-15

1.5KE130A 5.0µA, DO-201AD Transient Voltage Suppressor Pack of 5Pcs

Specification:

• Minimum Breakdown voltage: 124.0V
• Maximum Breakdown voltage: 137.0V
• Maximum Reverse Leakage Current: 5.0µa
• Maximum peak pulse current: 8.4A
• Maximum clamping voltage: 179.0V
• Maximum Temperature Coefficient of VBR: 0.107%
• Power Dissipation: 1500W
• Package: DO-201AD

KBPC8, KBPC806 8A 600V Bridge Rectifiers Diode pack of 2pcs

Specification

1. Case : KBPC8
2. Maximum respective peak reverse voltage : 600v
3. Maximum average rectified current : 8.0A
4. Maxim reverse current : 5.0µA
5. Non-Repetitive Peak Forward Surge Current : 250A
6. Maxim forward voltage : 1.1V

SA48A 1.0µA ,DO-15 Transient Voltage Suppressors Pack of 5pcs

Specification:-

• Breakover voltage : Min(V) 53.3 , Max(V) 58.9
• Maximum peak current : 6.5A
• Maximum reverse leakage current @ VRWM : 1.0µA
• Power dissipation :500W
• Package : DO-15

1.5KE440 5.0µA, DO-201AD Transient Voltage Suppressor Pack of 5Pcs

Specification:

• Minimum Breakdown voltage: 396.0V
• Maximum Breakdown voltage: 484.0V
• Maximum Reverse Leakage Current: 5.0µa
• Maximum peak pulse current: 2.3A
• Maximum clamping voltage: 630.0V
• Maximum Temperature Coefficient of VBR: 0.110%
• Power Dissipation: 1500W
• Package: DO-201AD
