SURFACE MOUNT SCHOTTKY BARRIER RECTIFIERS

SMA(G), SK33 30V Surface Mount Schottky Barrier Rectifiers Diode pack of 5pcs

Specification

1. Case : SMA(G)
2. Maximum respective peak reverse voltage : 30v
3. Maximum average rectified current : 1.0A
4. Maxim reverse current : 0.5µA
5. Non-Repetitive Peak Forward Surge Current : 100A
6. Maxim forward voltage : 0.55V

SS34-E3/52T 40V 2.0A SMD Schottky Barrier Rectifier SMD Diode Pack of 750

Specification:-

• Mounting Style: SMD/SMT
• Package/Case: SMB (DO-214AA)
• Max. repetitive reverse voltage: 100V
• Forward Current: 2 A
• Max. RMS voltage: 28V

SS34-E3/52T 40V 2.0A SMD Schottky Barrier Rectifier SMD Diode Pack of 50

Specification:-

• Mounting Style: SMD/SMT
• Package/Case: SMB (DO-214AA)
• Max. repetitive reverse voltage: 100V
• Forward Current: 2 A
• Max. RMS voltage: 28V

B1100B-13-F Diode Rectifier 100V 1A Surface Mount SMB / DO-214AA

Specification:-

• Package: SMD4 Gull Wing / DF-S
• No. of Pins: 2 Pins
• Forward Current: 1 A
• Reverse Current: 500 uA
• Forward Surge Current: 30 A
• Repetitive Reverse Voltage: 100 V
• Operating Temperature: -65°C to 150°C

B120-13 20V 1A Surface Mount SMA Schottky Barrier Rectifier Diode DO-214AC

Specification:-

• Package: SMA / DO-214AC
• Peak Repetitive Reverse Voltage: 20V
• RMS Reverse Voltage: 14V
• Average Rectified Output Current: 1.0A
• Single Half Sine-Wave Superimposed on Rated Load: 30A
• Operating and Storage Temperature Range: -65 °C  to 150 °C

B120B-13 1A Surface Mount SMA Schottky Barrier Rectifier Diode DO-214AC

Specification:-

• Package: SMB / DO-214AA
• Pin Count: 2
• Rep Pk Reverse Voltage-Max: 20 V
• Non-rep Pk Forward Current-Max: 30 A
• Reverse Current-Max: 500 µA
• Reverse Test Voltage: 20 V
• Operating and Storage Temperature Range: -65 °C  to 150 °C

MBRB1045 45V 10A Surface Mount Diodes Rectifier TO-263-3 (2 Leads + Tab) / D2PAK

Specification:-

• Package: TO-263-3 (2 Leads + Tab)  / D2PAK
• Forward Current: 10 A
• Repetitive Reverse Voltage: 45 V
• Forward Voltage: 840 mV
• Forward Surge Current: 150 A
• Reverse Current: 100 uA

MBRB20H100CT 100V 10A Surface Mount Array 1-Pair Common Cathode Diodes Rectifier TO-263-3 (2 Leads + Tab) / D2PAK

Specification:-

• Package: TO-263-3 (2 Leads + Tab)  / D2PAK
• Forward Current: 10 A
• Repetitive Reverse Voltage: 100 V
• Forward Voltage: 880 mV
• Forward Surge Current: 250 A
• Reverse Current: 6 mA
