TO-92 PACKAGE

BC237 100mA 45V TO-92 Package General purpose NPN transistor pack of 10 pcs

Specification

1. Collector-Emitter Voltage (VCEO): 45V
2. Continuous Collector Current (IC):  100mA
3. Transition Frequency (fT):  150MHz
4. DC Current Gain (hFE): 120-800
5. Operating Temperature Range: -55 - 150°C
6. Transistor type  :  NPN Transistor

BC517 1A 30V TO-92 Package General purpose NPN transistor pack of 10 pcs

Specification

1. Collector-Emitter Voltage (VCEO):30V
2. Continuous Collector Current (IC): 1A
3. Transition Frequency (fT): 250MHz
4. DC Current Gain (hFE): 30K
5. Operating Temperature Range: -55 - 150°C
6. Transistor type  :  NPN Transistor

BC546 100mA 65V TO-92 Package General purpose NPN transistor pack of 10 pcs

Specification

1. Collector-Emitter Voltage (VCEO): 65V
2. Continuous Collector Current (IC): 100mA
3. Transition Frequency (fT): 250MHz
4. DC Current Gain (hFE): 110-800
5. Operating Temperature Range: -55 - 150°C
6. Transistor type  :  NPN Transistor

BC368 1A 20V TO-92 Package General purpose NPN transistor pack of 10 pcs

Specification

1. Collector-Emitter Voltage (VCEO): 20V
2. Continuous Collector Current (IC):  1A
3. Transition Frequency (fT):  65MHz
4. DC Current Gain (hFE): 85-375
5. Operating Temperature Range: -55 - 150°C
6. Transistor type  :  NPN Transistor

BC238 100mA 25V TO-92 Package General purpose NPN transistor pack of 10 pcs

Specification

1. Collector-Emitter Voltage (VCEO): 25V
2. Continuous Collector Current (IC): 100mA
3. Transition Frequency (fT): 150MHz
4. DC Current Gain (hFE): 200-800
5. Operating Temperature Range:  -55 - 150°C
6. Transistor type  :  NPN Transistor

BC636, -1A, -45V TO-92 Package General purpose PNP transistor pack of 10pcs

Specification

1. Type:   Transistor
2. Polarity:   PNP
3. Collector - Emitter voltage:  -45 volts
4. Collector current:   -1A
5. Gain H(fe):  40/250
6. Power dissipation:  625 mW
7. F(t) minimum:  50 MHz
8. Package: TO-92
9. Max Storage & Operating temperature Should Be: -55 to +150 Centigrade

MPSA45 300mA 350V TO-92 Package NPN Darlington Transistors pack of 10 pcs

Specification

1. Collector-Emitter Voltage (VCEO): 350V
2. Continuous Collector Current (IC):  300mA
3. Transition Frequency (fT):  150MHz
4. DC Current Gain (hFE): 120-800
5. Operating Temperature Range: -55 - 150°C
6. Transistor type  :  NPN Transistor

BC338 800mA 25V TO-92 Package General purpose NPN transistor pack of 10 pcs

Specification

1. Collector-Emitter Voltage (VCEO): 25V
2. Continuous Collector Current (IC): 800mA
3. Transition Frequency (fT): 250MHz
4. DC Current Gain (hFE): 120-630
5. Operating Temperature Range: -55 - 150°C
6. Transistor type  :  NPN Transistor

BC337 800mA 45V TO-92 Package General purpose NPN transistor pack of 10 pcs

Specification

1. Collector-Emitter Voltage (VCEO): 45V
2. Continuous Collector Current (IC): 800mA
3. Transition Frequency (fT):  250MHz
4. DC Current Gain (hFE):  100-630
5. Operating Temperature Range: -55 - 150°C
6. Transistor type  :  NPN Transistor

2N2369 15V 200mA 625mW Through Hole NPN Bipolar Transistor TO-92

Specification:-

• Package: TO-92-3
• Transistor Polarity: NPN
• Configuration: Single
• Maximum DC Collector Current: 500 mA
• Collector- Emitter Voltage Max: 15 V
• Collector- Base Voltage: 40 V
• Emitter- Base Voltage: 4.5 V

S8050 3-Pin General-Purpose NPN Transistor To-92 Package

Specification:-

• Transistor Type: NPN
• Maximum Power: 2 Watts
• Maximum DC Current Gain:  400
• Continuous Collector current: 700mA
• Base- Emitter Voltage: 5V
• Collector-Emitter Voltage:20V
• Collector-Base Voltage:30V
