BMS HARDWARE

Showing 1–12 of 283 results

  • Smart ESS BMS LFP 15S 100A Common Port with Balance
    BMS HARDWARE
    Smart ESS BMS LFP 15S 100A Common Port with Balance
    Rs. 8429.00

    Specification:-

    • Cell specifications: 15 strings of LFP battery
    • Interface type: Charge and discharge are both at the same port
    • Charging voltage: 3.65V*Number of strings
    • Continuous charging current: 50A
    • Continuous discharging current: 100A
    • Consumption of running: ≤60mA
    (1)
    Rs. 8429.00
  • Smart BMS 3-4S 100A Same Port for Charge and Discharge (DP04S014)
    BMS HARDWARE
    Smart BMS 3-4S 100A Same Port for Charge and Discharge (DP04S014)
    Rs. 2479.00

    Specification:-

    • Cell specifications: 3~4 strings of LiFePO4 battery
    • Continuous current: 100A
    • Balance detect Voltage 3.8
    • Interface type: Charge and discharge are both at the same port
    • Charging voltage: 3.6V*Number of strings
    • Cell voltage range: 2.30~3.75V
    • Continuous charging current: 100A
    • Continuous discharging current: 100A
    (1)
    Rs. 2479.00
  • 8S 20A BMS LFP Hardware Waterproof
    BMS HARDWARE
    8S 20A BMS LFP Hardware Waterproof
    Rs. 639.00

    Specification:-

    • Battery Configuration: 8S for LiFePO4 (LFP) batteries
    • Continuous Discharge Current: 20A
    • Continuous Charge Current: 20A
    • Over-Voltage Protection: 3.75±0.05V
    • Balancing Current: 30±5mA
    • Charge Voltage: 29.2V
    • Working Temp: -20~70 °C
    • Working current: 100 uA
    (1)
    Rs. 639.00
  • 15S 200A BMS LFP Hardware Waterproof
    BMS HARDWARE
    15S 200A BMS LFP Hardware Waterproof
    Rs. 9069.00

    Specification:-

    • Battery Configuration: 15S for LiFePO4 (LFP) batteries
    • Continuous Discharge Current: 200A
    • Over-Voltage Protection: 3.8V
    • Balancing Current: 50mA
    • Charge Voltage: 54.75V
    (1)
    Rs. 9069.00
  • 8S 10A LFP LiFePO4 BMS 8181A Module
    BMS HARDWARE
    8S 10A LFP LiFePO4 BMS 8181A Module
    Rs. 459.00

    Specification:-

    • Model TDT-8S-8181A 10A LFP
    • Input Voltage B+ to B-: -0.3~+15V
    • Overcharge Detection voltage/1CELL: 3.65±0.05V
    • Over discharge Detection voltage/1CELL: 2.32±0.1V
    • Charge temperature protection 0°C~+50°C
    • Discharge temperature protection 65°C~+75°C
    (1)
    Rs. 459.00
  • 1S 2A NMC Round BMS Module Hardware
    BMS HARDWARE
    1S 2A NMC Round BMS Module Hardware
    Rs. 29.00

    Specification:-

    • Charging Voltage: DC 5V CC/CV
    • Max continuous charging current: 10A
    • Over charge detection voltage: 4.28±0.025V
    • Over discharge detection voltage: 3.0±05V
    • Over current detection current: 0.08±0.015A
    • Operating Temperature: -45°C to +65°C
    • Storage Temperature: -45°C to +85°C
    (1)
    Rs. 29.00
  • 16S 40A BMS NMC Hardware Waterproof
    BMS HARDWARE
    16S 40A BMS NMC Hardware Waterproof
    Rs. 1269.00

    Specification:-

    • Continuous Discharge Current: 40A
    • Over-Voltage Protection: 4.2V
    • Charge Current: 20A
    • Charge Voltage: 67.2V
    • Battery Configuration: 16S for NMC (Nickel Manganese Cobalt) Lithium-Ion
    (1)
    Rs. 1269.00
  • Smart BMS 8-24S 40A Same Port for Charge and Discharge (SP24S004)
    BMS HARDWARE
    Smart BMS 8-24S 40A Same Port for Charge and Discharge (SP24S004)
    Rs. 4079.00

    Specification:-

    • Cell specifications: 8~24 strings of LiFePO4 battery
    • Charging voltage: 3.60V*Number of strings
    • Cell voltage range: 2.20~3.75V
    • Continuous charging current: 40A
    • Continuous discharging current: 40A
    • Consumption of running: ≤20mA
    (1)
    Rs. 4079.00
  • 3S 10A NMC Battery Protection and Charger BMS Hardware with Nickel & Balance
    BMS HARDWARE
    3S 10A NMC Battery Protection and Charger BMS Hardware with Nickel & Balance
    Rs. 119.00

    Specification:-

    • Input Voltage B+ to B-: -0.3~+20V
    • Overcharge Detection voltage/1CELL: 4.28±0.05V
    • Over discharge Detection voltage/1CELL: 2.8±0.1V
    • Over current: 10-20A
    • Suggest working temperature: -20°C~+60°C
    (1)
    Rs. 119.00
  • 4S 20AMP LFP BMS Hardware
    BMS HARDWARE
    4S 20AMP LFP BMS Hardware
    Rs. 119.00

    Specification:-

    • Charging Voltage: DC 14.4V CC/CV
    • Max continuous charging current: 20A
    • Over charge detection voltage: 3.65±0.05V
    • Over discharge detection voltage: 2.33±0.1V
    • Over current detection current: 22.5±3A
    • Operating Temperature: -45°C to +65°C
    • Storage Temperature: -45°C to +85°C
    (1)
    Rs. 119.00
  • Smart BMS 10-17S 50A Same Port for Charge and Discharge (SP17S005)
    BMS HARDWARE
    Smart BMS 10-17S 50A Same Port for Charge and Discharge (SP17S005)
    Rs. 1989.00

    Specification:-

    • Cell specifications: 10~17 strings of Lithium Iron Battery
    • Interface type: Charge and discharge are both at the same port
    • Charging voltage: 4.20V*Number of strings
    • Cell voltage range: 2.8~4.25V
    • Continuous charging current: 50A
    • Continuous discharging current: 50A
    • Consumption of running: ≤10mA
    • Consumption of sleep: ≤500uA
    • Circuit resistance: ≤10mR
    • Operating temperature: -30°C~75°C
    (1)
    Rs. 1989.00
  • 7S 60A BMS NMC Hardware Waterproof
    BMS HARDWARE
    7S 60A BMS NMC Hardware Waterproof
    Rs. 1789.00

    Specification:-

    • Continuous Discharge Current: 60A
    • Over-Voltage Protection: 4.2V
    • Charge Current: 10A
    • Charge Voltage: 29.4V
    • Battery Configuration: 7S for NMC (Nickel Manganese Cobalt) Lithium-Ion
    (1)
    Rs. 1789.00
