SWITCHES

SPST momentary heavy duty rectangle shape Black color Push buttons Horn type switches pack of 100pcs

Specifications

1. Working voltage : 12V to 50V DC
2. Power rating : 5A
3. Application : Momentary
4. Type : SPST
5. Hard plastic body
6. Highly insulated

SMD Momentary Type 2 Pin Tactile Switch (3 x 6 x 2.5mm) Pack of 20

Specification:-

• Switch Type : Momentary
• Contact Type : Solder Type
• Mounting Type : SMD/SMT
• Voltage : 12V
• Operating Current (A) : 0.05
• Contact Resistance : 100mΩ (Max.)
• Length (mm) : 6mm
• Width (mm) : 3mm
• Height (mm) : 2.5mm

SS14D01 0.3A 30V SP4T 6 pin metal body panel mount plastic handles slide switches pack of 100pcs

Specification

1. 100% Original and best quality product
2. Type:  single pole, four pin throw
3. Mode of Operation   :  slide
4. Max. current withstand  :  50V
5. Max. power rating  :  2A
6. High temperature withstand
7. Long life approximately 10,000 clicks
8. High wear and tear properties
9. Durable and excellent design

KCD4 10A 250V AC black color 6 pins DPCO Heavy duty plastic rocker switches pack of 50pcs

Specification

1. 100% Original and best quality product
2. Type  :  Double pole, changeover, or triple throw
3. Max. current withstand  :  250V AC
4. Max. power rating  :  10A
5. It offers on/off switch one at a time
6. High temperature withstand
7. Long-life approximately 10,000 clicks
8. High wear and tear properties
9. Durable and excellent design

6 x 6 x 7mm Red color tactile momentary push button switch pack of 20pcs

Specification

1. Type : Through hole design.
2. Shaft Shape : Square
3. Mode of Operation   :  Tactile momentary
4. Number of pin : 4
5. Power Rating   :  MAX 50mA 24V DC
6. Insulation Resistance   :  100M ohm (Ω)
7. Operating Force  :  2.55±0.69 N
8. Dimensions are given at the image

16mm 5 Pin Metal Push Button Switch Wire Socket Connector Pack of 50

Specifications:-

• Operating Current: 2A
• Operating Voltage: 12VDC
• No. of Pins: 5 pin
• Mounting Hole: 16mm
• Material: Plastic, Metal
• Waterproof, Dust-Proof

KCD3 15A 250V AC black color 3 pins SPCO heavy duty plastic rocker switches pack of 50pcs

Specification

1. 100% Original and best quality product
2. Type  :  single pole, changeover, or triple throw
3. Max. current withstand  :  250V
4. Max. power rating  :  15A
5. It offers on/off switch one at a time
6. High temperature withstand
7. Long-life approximately 10,000 clicks
8. High wear and tear properties
9. Durable and excellent design

Manual 10 way DIP switches standard profile BD10 pack of 50pcs

Specifications

1. Switch function : SPST
2. Contact rating : 100 mAh max.
3. Pin space : 2.54mm
4. Operating Temperature Range : -40 to 85 °C
5. No. of pins : 20

SPST On and Off self lock momentary push button Blue color pack of 5pcs

Specifications

1. Working voltage : 12V to 30V DC
2. Power rating : 5A
3. Type : SPST
4. Application : Momentary
5. Color : Blue
6. Self lock
7. Hard plastic body
8. Highly insulated

PTS-09 3 pins ON/OFF/ON/OFF 1A 30V self lock tactile switches pack of 100pcs

Specification

1. Mode of operation : ON/OFF/ON/OFF
2. Power rating : 1A 30V
3. Number of pins : 3
4. Dimension of the switch : 12mm x 12mm x 9mm
5. Insulation Resistance   :  100M ohm (Ω)
6. Operating Force  :  2.55±0.69 N
7. Durable construction
8. Long lasting

SPST On and Off self lock momentary push button Yellow color pack of 10pcs

Specifications

1. Working voltage : 12V to 125V
2. Power rating : 5A
3. Type : SPST
4. Application : Momentary
5. Color : Yellow
6. Self lock
7. Hard plastic body
8. Highly insulated

6 x 6 x 7mm Blue color tactile momentary push button switches pack of 20pcs

Specification

1. Type                            Through Hole Design.
2. Shaft Shape                 Square
3. Number of Pin              4
4. Mode of Operation       Tactile momentary
5. Power Rating               MAX 50mA 24V DC
6. Insulation Resistance    100M ohm
7. Operating Force           2.55±0.69 N
