SWITCHES

6 x 6 x 14mm Red color tactile momentary push buttons switches pack of 1000pcs

Specification

1. Type : Through-hole design.
2. Shaft Shape : Square
3. Mode of Operation   :  Tactile momentary
4. Number of pin : 4
5. Power Rating   :  MAX 50mA 24V DC
6. Insulation Resistance   :  100M ohm (Ω)
7. Operating Force  :  2.55±0.69 N
8. Dimensions are given at the image

20Amp 250V 4 Pin Mini Toggle Switch ON / OFF, Orange Color 20pcs

Specification

1. Switch function: on/off
2. Material: metal body
3. Current rating: 20 amp
4. Voltage: 250v
5. High temperatures can withstand
6. Long-life approximately 10,000 clicks

12 x 12 x 8mm Black color tactile momentary push button switches pack of 100pcs

Specification

1. Type : Through hole design.
2. Shaft Shape : Square
3. Mode of Operation   :  Tactile
4. Number of pin : 4
5. Power Rating   :  MAX 50mA 24V DC
6. Insulation Resistance   :  100M ohm (Ω)
7. Operating Force  :  2.55±0.69 N

SS23D03 0.3A 30V DP3T 8 pin metal body panel mount plastic handles slide switches pack of 100pcs

Specification

1. 100% Original and best quality product
2. Type  :  Double pole, six terminal throw ( two pin at a time)
3. Mode of Operation   :  slide
4. Max. current withstand  :  250V
5. Max. power rating  :  5A
6. High temperature withstand
7. Long life approximately 10,000 clicks
8. High wear and tear properties
9. Durable and excellent design

NEXTWINNER KAN-28 8mm metal plate 5A/10A 250V SPST self locking tactile switch with wire attach pack of 10pcs

Specification:

• Mode of operation : SPST
• Rated current : 5A/10A
• Rated voltage : 125V to 250V
• Dimension of the switch : 12mm x 8mm
• Length of the plate : 8mm
• Insulation Resistance   :  >100MA ohm (Ω)
• Operating Force  :  2.55±0.69 N
• Durable construction
• Long lasting

Manual 5 way DIP switch standard profiles BD05 pack of 10pcs

Specifications

1. Switch function: SPST
2. Contact rating: 100 mAh max.
3. Pin space : 2.54mm
4. Operating Temperature Range : -40 to 85 °C
5. No. of pins : 10

TS23E01 15A 8 pins DP3T PCB mountable momentary slide toggle switches pack of 10pcs

Specification

1. Type  :  Momentary slide toggle switch
2. Function  :  DP3T ( double pole triple throw)
3. Power rating  :  15A
4. Dielectric strength  :  500V DC
5. Contact resistance  :  100mΩ
6. Metal body
7. Hard plastic handle

KCD1-101 Momentary Heavy Duty Rectangle Shape ON/OFF Self Lock Push Buttons Switches Pack of 100pcs

Specification

1. Rating                        6A 250V/10a 125v AC
2. Contact resistance     100mΩ
3. Insulation resistance  100mΩ
4. Temperature              -25°C to 85°C
5. Funcation                   push ON

KCD3 Rocker Switch Cover with Interlock for Dustproof and Waterproof Application Pack of 20

Specification:-

• Dimensions: 38mm x 19.5mm
• Waterproof Protection
• Easy Installation
• Soft rubber for a better experience
• Hard interlocking system
• Made from high-quality materials
• High industrial grade material manufactured

KCD3 15A 250V AC red color 3 pins SPCO heavy duty plastic rocker switches pack of 50pcs

Specification

1. 100% Original and best quality product
2. Type  :  single pole, changeover or triple throw
3. Max. current withstand  :  250V
4. Max. power rating  :  15A
5. It offers on/off switching one at a time
6. High temperature withstand
7. Long life approximately 10,000 clicks
8. High wear and tear properties
9. Durable and excellent design

PTS-09 2 pins ON/OFF 1A 30V self lock tactile switch pack of 20pcs

Specification

1. Mode of operation : SPST simple ON/OFF
2. Power rating : 1A 30V
3. Dimension of the switch : 12mm x 12mm x 9mm
4. Insulation Resistance   :  100M ohm (Ω)
5. Operating Force  :  2.55±0.69 N
6. Durable construction
7. Long lasting

16mm 12-24V Ring Light Push Button Self Lock Metal Switch with White Indicator

Specifications:-

• Operating Voltage: 12VDC
• Light Color: White
• Operating Current: 2A
• Number of pins: 5
• IP rating: IP65
• Waterproof And Dustproof
• Mounting Hole Diameter: 16 mm
• Body Material: Stainless Steel and Plastic
